Beacon & Light Mounting - Model Specific

All of our Stainless Steel Brackets are pre-drilled and cut from 14 gauge polished material. Options for all makes and most models of trucks available.

NOTE: Cab Style and orientation is often more important than Truck Model

FL22 Bracket for Freightliner M2 Class - L&R
Part No. Description WxDxH (in) Wt. (lbs)
FL22 Freightliner M2 Class Beacon Bracket 11 x 10.313 x 3.188 3.4
FL44 Bracket for Freightliner Day Cab - L&R
Part No. Description WxDxH (in) Wt. (lbs)
FL44 Freightliner Day Cab Beacon Bracket 10.25 x 12.688 x 8 5.1
IN44 10" Bracket for Int'l Day Cab - L&R
Part No. Description WxDxH (in) Wt. (lbs)
IN44 International Day Cab Beacon Bracket 9.75" 9.75 x 12.063 x 7.313 4.4
IN447 7" Bracket for Int'l Day Cabs - L&R
Part No. Description WxDxH (in) Wt. (lbs)
IN447 International Day Cab Beacon Bracket 7" 7 x 12.0623 x 7.313 3.1
Int'l 7000/4000 Day Cab Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
IN7040 International 7000 & 4000 Series Day Cab 13 x 8 x 3.25 2.8
KW25 for Kenworth Flat Top Day Cab - L&R
Part No. Description WxDxH (in) Wt. (lbs)
KW25 Kenworth Day Cab Beacon Bracket 10.25 x 12.688 x 9 5.1
KW39s for Kenworth Flat Glass Cab/B-Model
Part No. Description WxDxH (in) Wt. (lbs)
KW39L Kenworth B-Model Beacon Bracket, Drivers Side 10 x 13.75 x 12.438 5.1
KW39R Kenworth B-Model Beacon Bracket, Passengers Side 10 x 13.75 x 12.438 5.1
KW51s for Kenworth Flat-Top Sleepers
Part No. Description WxDxH (in) Wt. (lbs)
KW51L Kenworth Modular Flat Top Sleeper Beacon Bracket, Drivers Side 10.25 x 14 x 9.438 4
KW51R Kenworth Modular Flat Top Sleeper Beacon Bracket, Passengers Side 10.25 x 14 x 9.438 4
KW79s for Pre-2005 Kenworth Aero-cabs
Part No. Description WxDxH (in) Wt. (lbs)
KW79L Kenworth AeroCab Beacon Bracket (2005 and Older), Drivers Side 10.375 x 12.625 x 9.625 4.7
KW79R Kenworth AeroCab Beacon Bracket (2005 and Older), Passengers Side 10.375 x 12.625 x 9.625 4.7
KW81s for 2006+ Kenworth Aero-cabs
Part No. Description WxDxH (in) Wt. (lbs)
KW81L Kenworth Aerocab/B5 Cab Beacon Bracket (2006 and Newer), Drivers Side 9.125 x 11.25 x 9.375 3.1
KW81R Kenworth Aerocab/B5 Cab Beacon Bracket (2006 and Newer), Passengers Side 9.125 x 11.25 x 9.375 3.1
KW T300 Beacon Brackets
Part No. Description WxDxH (in) Wt. (lbs)
KW87L Kenworth T300 Beacon Bracket, Drivers Side 10.25 x 11.5 x 7.25 3.7
KW87R Kenworth T300 Beacon Bracket, Passengers Side 10.25 x 11.5 x 7.25 3.7
KW880s for T880, PB567 PACCAR Daycabs
Part No. Description WxDxH (in) Wt. (lbs)
KW880L Kenworth T880 / Peterbilt 567 Daycab Beacon Bracket, Drivers Side 14 x 10 x 6 2.7
KW880R Peterbilt 567 / Kenworth T880 Daycab Beacon Bracket, Passengers Side 14 x 10 x 6 2.7
MK21s for Mack CX High-Rise
Part No. Description WxDxH (in) Wt. (lbs)
MK21L Mack CX Model Beacon Bracket, Drivers Side 10 x 11.25 x 5.75 4.1
MK21R Mack CX Model Beacon Bracket, Passengers Side 10 x 11.25 x 5.75 4.1
MACK CH Day Cab Beacon Brackets-7"
Part No. Description WxDxH (in) Wt. (lbs)
MK24-07L MACK CH Day Cab Beacon Bracket, Drivers Side 7 x 11 x 6 3
MK24-07R MACK CH Day Cab Beacon Bracket, Passengers Side 7 x 11 x 6 3
MK24S for Mack CH D.Cab/ Titan Sleeper-10"
Part No. Description WxDxH (in) Wt. (lbs)
MK24L Mack CH Day Cab Beacon Bracket, Drivers Side 10 x 11 x 6 4.3
MK24R Mack CH Day Cab Beacon Bracket, Passengers Side 10 x 11 x 6 4.3
Peterbilt 579 & 567 High Roof Brackets
Part No. Description WxDxH (in) Wt. (lbs)
PB579L Peterbilt UltraCab Beacon Bracket, Drivers Side 10.375 x 12.625 x 11.625 5.1
PB579R Peterbilt UltraCab Beacon Bracket, Passengers Side 10.375 x 12.625 x 11.625 5.1
PB62 for Peterbilt Day Cab - L&R
Part No. Description WxDxH (in) Wt. (lbs)
PB62 Peterbilt Daycab Beacon Bracket 10.25 x 12.6875 x 9 4.8
PB71s for Peterbilt UltraCabs
Part No. Description WxDxH (in) Wt. (lbs)
PB71L Peterbilt UltraCab (2004 and up) Beacon Bracket, Drivers Side 10.25 x 11.438 x 13.563 5.1
PB71R Peterbilt UltraCab (2004 and up) Beacon Bracket, Passengers Side 10.25 x 11.4375 x 13.563 5.1
Sterling Beacon Brackets
Part No. Description WxDxH (in) Wt. (lbs)
ST61L Sterling Beacon Bracket, 10"W, 14ga BA SS - LEFT 11.4375 x 10 x 3.75 4
ST61R Sterling Beacon Bracket, 10"W, 14ga BA SS - RIGHT 11.4375 x 10 x 3.75 4
WS70 for Western Star Day Cabs - L&R
Part No. Description WxDxH (in) Wt. (lbs)
WS70 Western Star Day Cab Beacon Bracket, 11"W, 14ga BA SS - fits L&R 11 x 11.6 x 7 4.2
WS72s for W.Star Stratosphere Sleepers
Part No. Description WxDxH (in) Wt. (lbs)
WS72L Western Star Stratosphere Sleeper Beacon Bracket, cab mount, 10.375"W, 14ga BA SS - LEFT 12.6 x 10.4 x 12 5
WS72R Western Star Stratosphere Sleeper Beacon Bracket, cab mount, 10.375"W, 14ga BA SS - RIGHT 12.6 x 10.4 x 12 5
WS74 for W.Star Ultra-High Roof
Part No. Description WxDxH (in) Wt. (lbs)
WS74 Fits 2013 Stratosphere, fits L&R 11.5 x 15 x 8.5 4.4

Beacon & Light Mounting - Universal

All of our Stainless Steel Brackets are pre-drilled and cut from 14 gauge polished material

Hole patterns can be applicable to Grote, SWS and more…

Beacon Bracket, HD Alum - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G2000 Generic Aluminum Beacon Bracket 10 x 13 x 7 3
G411 2.5" Lamp Mount Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G411 Bracket for Back-up / Load Light, 2 light locations 2.5 x 3.125 x 7 0.6
G415 4" 5-hole Lamp Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G415 Bracket for Back-up / Load Light, 5 light locations 4 x 3 x 6 1.1
5.5" Small Side-Mount G472 Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G472-512 Small Side Mount Beacon Bracket 5.5" 5.5 x 7 x 11.5 2.5
6.25" Small Side Mount G472 Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G472-614 Small Side Mount Beacon Bracket 6.25" 6.25 x 7 x 11.5 2.8
Low-Profile Satelite G477 Bracket, Alum - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G477 Low Profile Aluminum Beacon/Satellite Bracket 8 x 10.375 x 1.625 1.5
G477-Q16113 Low Profile Aluminum Beacon/Satellite Bracket 8 x 10.375 x 2.188 1.5
10" G610 Corner Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G610-10 Volvo Beacon Bracket 10" 10 x 11.75 x 6 4.2
7" G10 Corner Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G610-7 Volvo Beacon Bracket 7" 7 x 11.75 x 6 2.9
G661 Beacon/Back-up Light Bracket, SS - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G661 Beacon / Back-up Light Bracket 7 x 7.1875 x 11.188 3.2
G663 Satellite / Beacon Combo Bracket
Part No. Description WxDxH (in) Wt. (lbs)
G663-10 Generic Beacon/Satellite Bracket 10.25 x 10.5 x 7.875 5.8
G664 for Fairing Mount w/ Backing Plates
Part No. Description WxDxH (in) Wt. (lbs)
G664-9 Fairing Mount 9 x 9 x 13 6.1
G670 7" Vertical Mount Bracket - L&R
Part No. Description WxDxH (in) Wt. (lbs)
G670-712 Generic Side Mount Beacon Bracket 7.5 x 8.75 x 13.813 3.4
G700 Mini Light Bar Bracket
Part No. Description WxDxH (in) Wt. (lbs)
G700 Mini Light Bar Bracket 21.5625 x 7.5 x 1.75 3.5

Boxes - 5 Bar

Stock sized medium duty under-body tool boxes with smooth .100 aluminum body and premium 5-bar pattern aluminum checker plate doors.

5-bar boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, and auto-grade bulb seal

5-Bar MD Underbody Boxes
Part No. Description WxDxH (in) Wt. (lbs)
5B181818 Aluminum Tool Box 18W 18D 18H Bottom hinged, with 5-Bar door 18 x 18 x 18 24
5B241818 Aluminum Tool Box 24W 18D 18H Bottom hinged, with 5-Bar door 24 x 18 x 18 29
5B242424 Aluminum Tool Box 24W 24D 24H Bottom hinged, with 5-Bar door 24 x 24 x 24 40
5B301818 Aluminum Tool Box 30W 18D 18H Bottom hinged, with 5-Bar door 30 x 18 x 18 34
5B302424 Aluminum Tool Box 30W 24D 24H Bottom hinged, with 5-Bar door 30 x 24 x 24 46
5B361818 Aluminum Tool Box 36W 18D 18H Bottom hinged, with 5-Bar door 36 x 18 x 18 39
5B362424 Aluminum Tool Box 36W 24D 24H Bottom hinged, with 5-Bar door 36 x 24 x 24 53
5B481818 Aluminum Tool Box 48W 18D 18H Bottom hinged, with 5-Bar door 48 x 18 x 18 50
5B482418 Aluminum Tool Box 48W 24D 18H Bottom hinged, with 5-Bar door 48 x 24 x 18 58
5B482424 Aluminum Tool Box 48W 24D 24H Bottom hinged, with 5-Bar door 48 x 24 x 24 67
5B601818 Aluminum Tool Box 60W 18D 18H Bottom hinged, with 5-Bar door 60 x 18 x 18 60

Boxes - Air Control

Air Control Boxes are hinged with corner bolts and may include glass ports, and fitting holes.

Custom dimensions and fitting allowance available for bulk orders. Contact factory for details.

Air Control Box w/ fitting holes
Part No. Description WxDxH (in) Wt. (lbs)
A830CK1 Air Control Box with Fitting Holes 10 x 6 x 7 5
Air Control Box 8W5D8H with window
Part No. Description WxDxH (in) Wt. (lbs)
ACB080508CPD-W Trailer Air Control Box 8.5 x 6 x 8.5 5

Boxes - Battery

Designed to mount directly to existing OE hardware with HD Aluminum construction.

Each component (base and lid) is ordered independently.

Battery Box for Peterbilt, Diamond Tread
Part No. Description WxDxH (in) Wt. (lbs)
PB70BB Battery Box Base for Peterbilt, Diamond Tread 30 x 31 x 16 40
Battery Box Covers w/ step for PB
Part No. Description WxDxH (in) Wt. (lbs)
PB70CP-DIA Battery Box Cover for Peterbilt, checker w/ Diamond Grip step 30.5 x 16 x 16.5 20
PB70SM-DIA Battery Box Cover for Peterbilt, smooth w/ Diamond Grip step 30.5 x 16 x 16.5 20
Battery Box Cover for WS
Part No. Description WxDxH (in) Wt. (lbs)
WS50 Battery Box Cover for Western Star, no step 32 x 22 x 13.5 18
WS51 Battery Box Cover for Western Star, w/ Round Grip step 32 x 22 x 13 24

Boxes - Boot Boxes

All our boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of finish, Whale Tail Latches, Alternative Hinge Location

Checker Plate Aluminum Boot Boxes
Part No. Description WxDxH (in) Wt. (lbs)
BB12CP Boot Box, 12" Wide, checker finish 12 x 20.5 x 23.75 29
BB14CP Boot Box, 14" Wide, checker finish 14 x 20.5 x 23.75 34
BB16CP Boot Box, 16" Wide, checker finish 16 x 20.5 x 23.75 39
BB18CP Boot Box, 18" Wide, checker finish 18 x 20.5 x 23.75 42
BB24CP Boot Box, 24" Wide, checker finish 20 x 20.5 x 23.75 43
BB36CP Boot Box, 36" Wide, checker finish 36 x 20.5 x 23.75 60
BB46CP Boot Box, 46" Wide, checker finish 46 x 20.5 x 23.75 66
Smooth Aluminum Boot Boxes
Part No. Description WxDxH (in) Wt. (lbs)
BB12SM Boot Box, 12" Wide, smooth finish 12 x 20.5 x 23.75 29
BB14SM Boot Box, 14" Wide, smooth finish 14 x 20.5 x 23.75 34
BB16SM Boot Box, 16" Wide, smooth finish 16 x 20.5 x 23.75 39
BB18SM Boot Box, 18" Wide, smooth finish 18 x 20.5 x 23.75 42
BB24SM Boot Box, 24" Wide, smooth finish 24 x 20.5 x 23.75 50
BB36SM Boot Box, 36" Wide, smooth finish 36 x 20.5 x 23.75 60
Checker Plate Aluminum XL-Lid Boot Boxes
Part No. Description WxDxH (in) Wt. (lbs)
BBX12CP XL Lid Boot Box, 12" Wide, checkerplate finish 12 x 20 x 22.5 28
BBX14CP XL Lid Boot Box, 14" Wide, checkerplate finish 14 x 20 x 22.5 30
BBX16CP XL Lid Boot Box, 16" Wide, checkerplate finish 16 x 20 x 22.5 32
BBX18CP XL Lid Boot Box, 18" Wide, checkerplate finish 18 x 20 x 22.5 34
BBX24CP XL Lid Boot Box, 24" Wide, checkerplate finish 24 x 20 x 22.5 36
BBX36CP XL Lid Boot Box, 36" Wide, checkerplate finish 36 x 20 x 22.5 38
Smooth Aluminum XL-Lid Boot Boxes
Part No. Description WxDxH (in) Wt. (lbs)
BBX12SM XL Lid Boot Box, 12" Wide, smooth finish 12 x 20 x 22.5 28
BBX14SM XL Lid Boot Box, 14" Wide, smooth finish 14 x 20 x 22.5 30
BBX16SM XL Lid Boot Box, 16" Wide, smooth finish 16 x 20 x 22.5 32
BBX18SM XL Lid Boot Box, 18" Wide, smooth finish 18 x 20 x 22.5 34
BBX24SM XL Lid Boot Box, 24" Wide, smooth finish 24 x 20 x 22.5 36
BBX36SM XL Lid Boot Box, 36" Wide, smooth finish 36 x 20 x 22.5 38

Boxes - Box Mounting Bracket

Mounting options in steel and aluminum to fit most truck frame and trailer applications.

Additional spacers, reinforcements and custom dimensions are available on request.

Angle Bracket Box-Mounting Kits
Part No. Description WxDxH (in) Wt. (lbs)
T81 Box Mounting Kit, galvanized, pair 3 x 20.5 x 23.5 26
T81-2.5 Box Mounting Kit, galvanized, pair, 2.5" standoff 3 x 20.5 x 23.5 26
T81N Box Mounting Kit, galvanized, pair 3 x 10.5 x 23.5 20.23
Aluminum Hanging-Style Box Mount
Part No. Description WxDxH (in) Wt. (lbs)
T82 Box Mounting Kit, hanging style for Trailer boxes, 3/16" aluminum, pair 21 x 16 x 2.5 15
T85 Box Mounting Kit, hanging style for small boxes, 3/16" aluminum, pair 12 x 14 x 3 8.6

Boxes - Double Flush Door

All our boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Compatible with T81 (Angle) Mount Kits. Options include: Choice of smooth or checker plate finish, latch upgrades, .

3 Ft Double Flush Door Boxes
Part No. Description WxDxH (in) Wt. (lbs)
DF361818 Aluminum Box, Double Flush, 36Wx18Dx18H, smooth finish 36 x 18 x 18 55
DF361818CP Aluminum Box, Double Flush, 36Wx18Dx18H, checker finish 36 x 18 x 18 67
DF362424 Aluminum Box, Double Flush, 36Wx24Dx24H, smooth finish 36 x 24 x 24 71
DF362424CP Aluminum Box, Double Flush, 36Wx24Dx24H, checker finish 36 x 24 x 24 75
4 Ft Double Flush Door Boxes
Part No. Description WxDxH (in) Wt. (lbs)
DF481818 Aluminum Box, Double Flush, 48Wx18Dx18H, smooth finish 48 x 18 x 18 62
DF452418 Aluminum Box, Double Flush, 45Wx24Dx18H, smooth finish 45 x 24 x 18 71
DF452418CP Aluminum Box, Double Flush, 45Wx24Dx18H, checker finish 45 x 24 x 18 75
DF481818CP Aluminum Box, Double Flush, 48Wx18Dx18H, checker finish 48 x 18 x 18 75
DF482418 Aluminum Box, Double Flush, 48Wx24Dx18H, smooth finish 48 x 24 x 18 75
DF482418CP Aluminum Box, Double Flush, 48Wx24Dx18H, checker finish 48 x 24 x 18 80
DF482424 Aluminum Box, Double Flush, 48Wx24Dx24H, smooth finish 48 x 24 x 24 87
DF482424CP Aluminum Box, Double Flush, 48Wx24Dx24H, checker finish 48 x 24 x 24 93
5 Ft Double Flush Door Boxes
Part No. Description WxDxH (in) Wt. (lbs)
DF602424 Aluminum Box, Double Flush, 60Wx24Dx24H, smooth finish 60 x 24 x 24 103
DF552424 Aluminum Box, Double Flush, 55Wx24Dx24H, smooth finish 55 x 24 x 24 96
DF601818 Aluminum Box, Double Flush, 60Wx18Dx18H, smooth finish 60 x 18 x 18 78
DF601818CP Aluminum Box, Double Flush, 60Wx18Dx18H, checker finish 60 x 18 x 18 82
DF602418 Aluminum Box, Double Flush, 60Wx24Dx18H, smooth finish 60 x 24 x 18 89
DF602418CP Aluminum Box, Double Flush, 60Wx24Dx18H, checker finish 60 x 24 x 18 95
DF602424CP Aluminum Box, Double Flush, 60Wx24Dx24H, checker finish 60 x 24 x 24 109
DF602430 Aluminum Box, Double Flush, 60Wx24Dx30H, smooth finish 60 x 24 x 30 105

Boxes - Full Door

All our boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of smooth or checker plate finish, Whale Tail Latch upgrade, and alternative hinge location.

2 FT Cube Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB242424LH Aluminum Box, Full Door, 24Wx24Dx24H, smooth finish, Left Hinge 24 x 24 x 24 52
AB242424BH Aluminum Box, Full Door, 24Wx24Dx24H, smooth finish, Bottom Hinge 24 x 24 x 24 52
AB242424BH-CP Aluminum Box, Full Door, 24Wx24Dx24H, checker finish, Bottom Hinge 24 x 24 x 24 56
AB242424LH-CP Aluminum Box, Full Door, 24Wx24Dx24H, checker finish, Left Hinge 24 x 24 x 24 52
AB242424RH Aluminum Box, Full Door, 24Wx24Dx24H, smooth finish, Right Hinge 24 x 24 x 24 52
2 Ft Under-Body Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB241818BH Aluminum Box, Full Door, 24Wx18Dx18H, smooth finish, Bottom Hinge 24 x 18 x 18 38
AB241818BH-CP Aluminum Box, Full Door, 24Wx18Dx18H, checker finish, Bottom Hinge 24 x 18 x 18 41
AB242416BH Aluminum Box, Full Door, 24Wx24Dx16H, smooth finish, Bottom Hinge 24 x 24 x 16 42
AB242418BH Aluminum Box, Full Door, 24Wx24Dx18H, smooth finish, Bottom Hinge 24 x 24 x 18 45
AB242418BH-CP Aluminum Box, Full Door, 24Wx24Dx18H, checker finish, Bottom Hinge 24 x 24 x 18 47
12" Full Door Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB122424LH-CP Aluminum Box, Full Door, 12Wx24Dx24H, checker finish, Left Hinge 12 x 24 x 24 38
AB121215LH-CP Aluminum Box, Full Door, 12Wx12Dx15H, checker finish, Left Hinge 12 x 12 x 15 16
AB122424RH-CP Aluminum Box, Full Door, 12Wx24Dx24H, checker finish, Right Hinge 12 x 24 x 24 38
AB142424LH-CP Aluminum Box, Full Door, 14Wx24Dx24H, checker finish, Left Hinge 14 x 24 x 24 39
18" Full Door Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB181818BH Aluminum Box, Full Door, 18Wx18Dx18H, smooth finish, Bottom Hinge 18 x 18 x 18 27
AB181818BH-CP Aluminum Box, Full Door, 18Wx18Dx18H, checker finish, Bottom Hinge 18 x 18 x 18 27
AB181824BH Aluminum Box, Full Door, 18Wx18Dx24H, smooth finish, Bottom Hinge 18 x 18 x 24 32
AB181824BH-CP Aluminum Box, Full Door, 18Wx18Dx24H, checker finish, Bottom Hinge 18 x 18 x 24 34
AB181824LH Aluminum Box, Full Door, 18Wx18Dx24H, smooth finish, Left Hinge 18 x 18 x 24 32
AB182424RH-CP Aluminum Box, Full Door, 18Wx24Dx24H, checker finish, Right Hinge 18 x 24 x 24 39
30" Under-Body Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB301818BH Aluminum Box, Full Door, 30Wx18Dx18H, smooth finish, Bottom Hinge 30 x 18 x 18 45
AB301818BH-CP Aluminum Box, Full Door, 30Wx18Dx18H, checker finish, Bottom Hinge 30 x 18 x 18 47
AB302424BH Aluminum Box, Full Door, 30Wx24Dx24H, smooth finish, Bottom Hinge 30 x 18 x 18 61
AB302424BH-CP Aluminum Box, Full Door, 30Wx24Dx24H, checker finish, Bottom Hinge 30 x 24 x 24 64
AB302424RH-CP Aluminum Box, Full Door, 30Wx24Dx24H, checker finish, Right Hinge 30 x 24 x 24 64
3 FT Under-Body Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB361818BH Aluminum Box, Full Door, 36Wx18Dx18H, smooth finish, Bottom Hinge 36 x 18 x 18 51
AB361416BH-CP Aluminum Box, Full Door, 36Wx14Dx16H, checker finish, Bottom Hinge 32 x 14 x 16 39
AB361818BH-CP Aluminum Box, Full Door, 36Wx18Dx18H, checker finish, Bottom Hinge 36 x 18 x 18 54
AB362418BH Aluminum Box, Full Door, 36Wx24Dx18H, smooth finish, Bottom Hinge 36 x 24 x 18 59
AB362418BH-CP Aluminum Box, Full Door, 36Wx24Dx18H, checker finish, Bottom Hinge 36 x 24 x 18 62
AB362424BH Aluminum Box, Full Door, 36Wx24Dx24H, smooth finish, Bottom Hinge 36 x 24 x 24 69
AB362424BH-CP Aluminum Box, Full Door, 36Wx24Dx24H, checker finish, Bottom Hinge 36 x 24 x 24 73
AB432424BH Aluminum Box, Full Door, 43Wx24Dx24H, smooth finish, Bottom Hinge 43 x 24 x 24 78
4 FT Under-Body Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB481818BH Aluminum Box, Full Door, 48Wx18Dx18H, smooth finish, Bottom Hinge 48 x 18 x 18 65
AB481818BH-CP Aluminum Box, Full Door, 48Wx18Dx18H, checker finish, Bottom Hinge 48 x 18 x 18 69
AB482424BH Aluminum Box, Full Door, 48Wx24Dx24H, smooth finish, Bottom Hinge 48 x 24 x 24 85
AB482424BH-CP Aluminum Box, Full Door, 48Wx24Dx24H, checker finish, Bottom Hinge 48 x 24 x 24 90
5 FT Under-Body Tool Boxes
Part No. Description WxDxH (in) Wt. (lbs)
AB601818BH Aluminum Box, Full Door, 60Wx18Dx18H, smooth finish, Bottom Hinge 60 x 18 x 18 82
AB601818BH-CP Aluminum Box, Full Door, 60Wx18Dx18H, checker finish, Bottom Hinge 60 x 18 x 18 82
AB602418BH Aluminum Box, Full Door, 60Wx24Dx18H, smooth finish, Bottom Hinge 60 x 24 x 18 88
AB602418BH-CP Aluminum Box, Full Door, 60Wx24Dx18H, checker finish, Bottom Hinge 60 x 24 x 18 94
AB602424BH Aluminum Box, Full Door, 60Wx24Dx24H, smooth finish, Bottom Hinge 60 x 24 x 24 101

Boxes - In-frame & X-frame Boxes

For use behind the cab, on or in the frame. Features include drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Ships with required hardware for frame mounting. Additional configurations and sizes for these applications are available on request. Contact factory for details.

In-frame Box
Part No. Description WxDxH (in) Wt. (lbs)
IF220924 In-frame Storage Box 33.5 x 24 x 9 39
IFN221224 In-frame Storage Box 33.5 x 24 x 12 39

Boxes - Single Flush Door

All our boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of smooth or checker plate finish, Whale Tail Latch upgrade, and alternative hinge location.

Single Flush Door Boxes
Part No. Description WxDxH (in) Wt. (lbs)
SF202424RH Aluminum Box, Flush Door, 20Wx24Dx24H, smooth finished, right hinged 20 x 24 x 24 45
SF242424BH Aluminum Box, Flush Door, 24Wx24Dx24H, smooth finished, bottom hinged 24 x 24 x 24 56
SF242424BH-CP Aluminum Box, Flush Door, 24Wx24Dx24H, checker finished, bottom hinged 24 x 24 x 24 56
SF242424LH Aluminum Box, Flush Door, 24Wx24Dx24H, smooth finished, left hinged 24 x 24 x 24 56
SF242424LH-CP Aluminum Box, Flush Door, 24Wx24Dx24H, checker finished, left hinged 24 x 24 x 24 56
SF242424RH Aluminum Box, Flush Door, 24Wx24Dx24H, smooth finished, right hinged 24 x 24 x 24 56
SF242424RH-CP Aluminum Box, Flush Door, 24Wx24Dx24H, checker finished, right hinged 24 x 24 x 24 56

Boxes - Sloped Lid Boxes

All our boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of smooth or checker plate finish, Whale Tail Latch upgrade, and alternative hinge location.

Cross-frame Box
Part No. Description WxDxH (in) Wt. (lbs)
XF331414 Cross Frame Box 33 x 14 x 14 68
SLB181717TH-CP Slope Lid Box, checker finish 18 x 17 x 17 40

Boxes - Step Boxes

All our boxes come standard with Locking T-Handle latch and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of Round Or Diamond Step pattern, smooth or checker plate finish, Whale Tail Latch upgrade, and alternative hinge location.

Low Profile Step Boxes
Part No. Description WxDxH (in) Wt. (lbs)
LPSB12RND-CP Low Profile Step Box, 12" Wide, Round Grip, checker finish 12 x 28 x 20 28
LPSB18RND-CP Low Profile Step Box, 18" Wide, Round Grip, checker finish 18 x 28 x 20 35
Diamond Grip Step Boxes - Checker Plate
Part No. Description WxDxH (in) Wt. (lbs)
SB12DIA-CP Step Box, 12" Wide, Diamond Grip, checker finish 12 x 30 x 26 39
SB14DIA-CP Step Box, 14" Wide, Diamond Grip, checker finish 14 x 30 x 26 42
SB16DIA-CP Step Box, 16" Wide, Diamond Grip, checker finish 16 x 30 x 26 45
SB18DIA-CP Step Box, 18" Wide, Diamond Grip, checker finish 18 x 30 x 26 48
SB24DIA-CP Step Box, 24" Wide, Diamond Grip, checker finish 24 x 30 x 26 57
SB36DIA-CP Step Box, 36" Wide, Diamond Grip, checker finish 36 x 30 x 26 75
Diamond Grip Step Boxes - Smooth
Part No. Description WxDxH (in) Wt. (lbs)
SB12DIA-SM Step Box, 12" Wide, Diamond Grip, smooth finish 12 x 30 x 26 39
SB14DIA-SM Step Box, 14" Wide, Diamond Grip, smooth finish 14 x 30 x 26 42
SB16DIA-SM Step Box, 16" Wide, Diamond Grip, smooth finish 16 x 30 x 26 45
SB18DIA-SM Step Box, 18" Wide, Diamond Grip, smooth finish 18 x 30 x 26 48
SB24DIA-SM Step Box, 24" Wide, Diamond Grip, smooth finish 24 x 30 x 26 57
SB36DIA-SM Step Box, 36" Wide, Diamond Grip, smooth finish 36 x 30 x 26 75
Round Grip Step Boxes - Checker Plate
Part No. Description WxDxH (in) Wt. (lbs)
SB12RND-CP Step Box, 12" Wide, Round Grip steps, checker finish 12 x 30 x 26 39
SB14RND-CP Step Box, 14" Wide, Round Grip steps, checker finish 14 x 30 x 26 42
SB16RND-CP Step Box, 16" Wide, Round Grip steps, checker finish 16 x 30 x 26 45
SB18RND-CP Step Box, 18" Wide, Round Grip steps, checker finish 18 x 30 x 26 48
SB20RND-CP Step Box, 20" Wide, Round Grip steps, checker finish 20 x 30 x 26 51
SB24RND-CP Step Box, 24" Wide, Round Grip steps, checker finish 24 x 30 x 26 57
SB30RND-CP Step Box, 30" Wide, Round Grip steps, checker finish 30 x 30 x 26 66
SB32RND-CP Step Box, 32" Wide, Round Grip steps, checker finish 32 x 30 x 26 69
SB34RND-CP Step Box, 34" Wide, Round Grip steps, checker finish 34 x 30 x 26 72
SB36RND-CP Step Box, 36" Wide, Round Grip steps, checker finish 36 x 30 x 26 75
Round Grip Step Boxes - Smooth
Part No. Description WxDxH (in) Wt. (lbs)
SB12RND-SM Step Box, 12" Wide, Round Grip, smooth finish 12 x 30 x 26 39
SB14RND-SM Step Box, 14" Wide, Round Grip, smooth finish 14 x 30 x 26 42
SB16RND-SM Step Box, 16" Wide, Round Grip, smooth finish 16 x 30 x 26 45
SB18RND-SM Step Box, 18" Wide, Round Grip, smooth finish 18 x 30 x 26 48
SB24RND-SM Step Box, 24" Wide, Round Grip, smooth finish 24 x 30 x 26 57
SB36RND-SM Step Box, 36" Wide, Round Grip, smooth finish 36 x 30 x 26 75
Diamond Grip Notched Step Boxes - Checker Plate
Part No. Description WxDxH (in) Wt. (lbs)
SBN12DIA-CP-DS Notched Step Box, DS, 12"W, Diamond Grip, checker finish 12 x 30 x 26 41
SBN12DIA-CP-PS Notched Step Box, PS, 12"W, Diamond Grip, checker finish 12 x 30 x 26 41
SBN14DIA-CP-DS Notched Step Box, DS, 14"W, Diamond Grip, checker finish 14 x 30 x 26 43
SBN14DIA-CP-PS Notched Step Box, PS, 14"W, Diamond Grip, checker finish 14 x 30 x 26 43
SBN16DIA-CP-DS Notched Step Box, DS, 16"W, Diamond Grip, checker finish 16 x 30 x 26 46
SBN16DIA-CP-PS Notched Step Box, PS, 16"W, Diamond Grip, checker finish 16 x 30 x 26 46
SBN18DIA-CP-DS Notched Step Box, DS, 18"W, Diamond Grip, checker finish 18 x 30 x 26 49
SBN18DIA-CP-PS Notched Step Box, PS, 18"W, Diamond Grip, checker finish 18 x 30 x 26 49
SBN20DIA-CP-DS Notched Step Box, DS, 20"W, Diamond Grip, checker finish 20 x 30 x 26 52
SBN20DIA-CP-PS Notched Step Box, PS, 20"W, Diamond Grip, checker finish 20 x 30 x 26 52
Diamond Grip Notched Step Boxes - Smooth
Part No. Description WxDxH (in) Wt. (lbs)
SBN12DIA-SM-DS Notched Step Box, DS, 12"W, Diamond Grip, smooth finish 12 x 30 x 26 41
SBN12DIA-SM-PS Notched Step Box, PS, 12"W, Diamond Grip, smooth finish 12 x 30 x 26 41
SBN14DIA-SM-DS Notched Step Box, DS, 14"W, Diamond Grip, smooth finish 14 x 30 x 26 43
SBN14DIA-SM-PS Notched Step Box, PS, 14"W, Diamond Grip, smooth finish 14 x 30 x 26 43
SBN16DIA-SM-DS Notched Step Box, DS, 16"W, Diamond Grip, smooth finish 16 x 30 x 26 46
SBN16DIA-SM-PS Notched Step Box, PS, 16"W, Diamond Grip, smooth finish 16 x 30 x 26 46
SBN18DIA-SM-DS Notched Step Box, DS, 18"W, Diamond Grip, smooth finish 18 x 30 x 26 49
SBN18DIA-SM-PS Notched Step Box, PS, 18"W, Diamond Grip, smooth finish 18 x 30 x 26 49
SBN20DIA-SM-DS Notched Step Box, DS, 20"W, Diamond Grip, smooth finish 20 x 30 x 26 52
SBN20DIA-SM-PS Notched Step Box, PS, 20"W, Diamond Grip, smooth finish 20 x 30 x 26 52
Round Grip Notched Step Boxes - Checker Plate
Part No. Description WxDxH (in) Wt. (lbs)
SBN12RND-CP-DS Notched Step Box, DS, 12"W, Round Grip, checker finish 12 x 30 x 26 41
SBN12RND-CP-PS Notched Step Box, PS, 12"W, Round Grip, checker finish 12 x 30 x 26 41
SBN14RND-CP-DS Notched Step Box, DS, 14"W, Round Grip, checker finish 14 x 30 x 26 43
SBN14RND-CP-PS Notched Step Box, PS, 14"W, Round Grip, checker finish 14 x 30 x 26 43
SBN16RND-CP-DS Notched Step Box, DS, 16"W, Round Grip, checker finish 16 x 30 x 26 46
SBN16RND-CP-PS Notched Step Box, PS, 16"W, Round Grip, checker finish 16 x 30 x 26 46
SBN18RND-CP-DS Notched Step Box, DS, 18"W, Round Grip, checker finish 18 x 30 x 26 49
SBN18RND-CP-PS Notched Step Box, PS, 18"W, Round Grip, checker finish 18 x 30 x 26 49
SBN20RND-CP-DS Notched Step Box, DS, 20"W, Round Grip, checker finish 20 x 30 x 26 52
SBN20RND-CP-PS Notched Step Box, PS, 20"W, Round Grip, checker finish 20 x 30 x 26 52
SBN24RND-CP-DS Notched Step Box, DS, 24"W, Round Grip, checker finish 24 x 30 x 26 58
SBN24RND-CP-PS Notched Step Box, PS, 24"W, Round Grip, checker finish 24 x 30 x 26 58
Round Grip Notched Step Boxes - Smooth
Part No. Description WxDxH (in) Wt. (lbs)
SBN12RND-SM-DS Notched Step Box, DS, 12"W, Round Grip, smooth finish 12 x 30 x 26 41
SBN12RND-SM-PS Notched Step Box, PS, 12"W, Round Grip, smooth finish 12 x 30 x 26 41
SBN14RND-SM-DS Notched Step Box, DS, 14"W, Round Grip, smooth finish 14 x 30 x 26 43
SBN14RND-SM-PS Notched Step Box, PS, 14"W, Round Grip, smooth finish 14 x 30 x 26 43
SBN16RND-SM-DS Notched Step Box, DS, 16"W, Round Grip, smooth finish 16 x 30 x 26 46
SBN16RND-SM-PS Notched Step Box, PS, 16"W, Round Grip, smooth finish 16 x 30 x 26 46
SBN18RND-SM-DS Notched Step Box, DS, 18"W, Round Grip, smooth finish 18 x 30 x 26 49
SBN18RND-SM-PS Notched Step Box, PS, 18"W, Round Grip, smooth finish 18 x 30 x 26 49
SBN20RND-SM-DS Notched Step Box, DS, 20"W, Round Grip, smooth finish 20 x 30 x 26 52
SBN20RND-SM-PS Notched Step Box, PS, 20"W, Round Grip, smooth finish 20 x 30 x 26 52
Diamond Grip XL Lid XL-Lid Step Boxes - Checker Plate
Part No. Description WxDxH (in) Wt. (lbs)
SBX12DIA-CP XL-Lid Step Box, 12" Wide, Diamond Grip, checker finish 12 x 30 x 24 39
SBX14DIA-CP XL-Lid Step Box, 14" Wide, Diamond Grip, checker finish 14 x 30 x 24 41
SBX16DIA-CP XL-Lid Step Box, 16" Wide, Diamond Grip, checker finish 16 x 30 x 24 44
SBX18DIA-CP XL-Lid Step Box, 18" Wide, Diamond Grip, checker finish 18 x 30 x 24 45
SBX24DIA-CP XL-Lid Step Box, 24" Wide, Diamond Grip, checker finish 24 x 30 x 24 56
SBX36DIA-CP XL-Lid Step Box, 36" Wide, Diamond Grip, checker finish 36 x 30 x 24 74
Diamond Grip XL Lid XL-Lid Step Boxes - Smooth
Part No. Description WxDxH (in) Wt. (lbs)
SBX12DIA-SM XL-Lid Step Box, 12" Wide, Diamond Grip, smooth finish 12 x 30 x 24 37
SBX14DIA-SM XL-Lid Step Box, 14" Wide, Diamond Grip, smooth finish 14 x 30 x 24 39
SBX16DIA-SM XL-Lid Step Box, 16" Wide, Diamond Grip, smooth finish 16 x 30 x 24 42
SBX18DIA-SM XL-Lid Step Box, 18" Wide, Diamond Grip, smooth finish 18 x 30 x 24 47
SBX24DIA-SM XL-Lid Step Box, 24" Wide, Diamond Grip, smooth finish 24 x 30 x 24 54
SBX36DIA-SM XL-Lid Step Box, 36" Wide, Diamond Grip, smooth finish 36 x 30 x 24 71
Round Grip XL Lid XL-Lid Step Boxes - Checker Plate
Part No. Description WxDxH (in) Wt. (lbs)
SBX12RND-CP XL-Lid Step Box, 12" Wide, Round Grip steps, checker finish 12 x 30 x 24 39
SBX14RND-CP XL-Lid Step Box, 14" Wide, Round Grip steps, checker finish 14 x 30 x 24 42
SBX16RND-CP XL-Lid Step Box, 16" Wide, Round Grip steps, checker finish 16 x 30 x 24 45
SBX18RND-CP XL-Lid Step Box, 18" Wide, Round Grip steps, checker finish 18 x 30 x 24 45
SBX24RND-CP XL-Lid Step Box, 24" Wide, Round Grip steps, checker finish 24 x 30 x 24 57
SBX36RND-CP XL-Lid Step Box, 36" Wide, Round Grip steps, checker finish 36 x 30 x 24 75
Round Grip XL Lid XL-Lid Step Boxes - Smooth
Part No. Description WxDxH (in) Wt. (lbs)
SBX12RND-SM XL-Lid Step Box, 12" Wide, Round Grip, smooth finish 12 x 30 x 24 37
SBX14RND-SM XL-Lid Step Box, 14" Wide, Round Grip, smooth finish 14 x 30 x 24 39
SBX16RND-SM XL-Lid Step Box, 16" Wide, Round Grip, smooth finish 16 x 30 x 24 43
SBX18RND-SM XL-Lid Step Box, 18" Wide, Round Grip, smooth finish 18 x 30 x 24 48
SBX24RND-SM XL-Lid Step Box, 24" Wide, Round Grip, smooth finish 24 x 30 x 24 55
SBX36RND-SM XL-Lid Step Box, 36" Wide, Round Grip, smooth finish 36 x 30 x 24 72

Cab Guards - Accessories

Premium ACE-manufactured accessories to fit one, or more of our Cab Guard series.

Just like our Cab Guards themselves, our accessories can be customized, if you don't see what you need for your application call our product desk for more options.

Beacon & Lamp Mounts
Part No. Description WxDxH (in) Wt. (lbs)
BP8X36 Beacon Pole 8" W Round X 36H - bolt-on, hardware incl. 8 x 8 x 36 6.5
Headache Rack Chain Hangers w/ Lids
Part No. Description WxDxH (in) Wt. (lbs)
C22 Chain Hanger for 3/8" chains, 10 slots 22.5 x 5 x 2.6875 4.5
C22HD Chain Hanger for 1/2" chains, 8 slots 22.5 x 4.75 x 3.25 6.5
Airline Manifold Plates
Part No. Description WxDxH (in) Wt. (lbs)
CR3A-AMP-1 Airline Manifold Plate - air & electrical connections 31.5 x 1.625 x 11.75 23
CR3A-AMP-2 Airline Manifold Plate - air, electrical & hydraulic connections 31.5 x 1.625 x 11.75 21
CR3A-AMP-3 Airline Manifold Plate - air, electrical & hydraulic connections 31.5 x 1.625 x 11.75 21
Cabinet Rack Beacon & Lamp Mounts
Part No. Description WxDxH (in) Wt. (lbs)
CR3A-MLB-KIT Mini Light bar Bracket Kit for Cabinet Racks, pair, bolt-on 20.5 x 7 x 9 9.5
Cab Guard Light-Bar Platforms
Part No. Description WxDxH (in) Wt. (lbs)
CRA-LP4312 Light Bar Platform for Cabinet Racks 4.5 x 43 x 12 0
HRA-LP43 Light Bar Mount for Headache Racks 4.5 x 43 x 36.5 0
Headache Rack Short Chain Tray
Part No. Description WxDxH (in) Wt. (lbs)
CT24 Short Chain Tray, Bolt-on 24 x 7.5 x 9.75 9.5
HR Full-Width Chain Tray
Part No. Description WxDxH (in) Wt. (lbs)
CT79 Full Width Chain Tray 79"W, aluminum, bolt-on - for HR1 & HR2 Series Racks 78.813 x 8.25 x 9.75 1.8
CT80 Full Width Chain Tray 80"W, aluminum, weld-on - for HR1 & HR2 Series Racks 79.875 x 6.625 x 10 1.8
Flip D Signs for Cab Guards
Part No. Description WxDxH (in) Wt. (lbs)
FDS-HD Flip "D" Sign, 72" Wide, bolt-on 72 x 3 x 44.5 47
Bolt On Curved Grab Handles
Part No. Description WxDxH (in) Wt. (lbs)
GH-PCM-27 Grab Handle 27", bolt on 5.6875 x 6 x 27 2
GH-PCM-36 Grab Handle 36", bolt on 5.6875 x 6 x 36 2
Heavy Duty U-Bolt Mount Kits
Part No. Description WxDxH (in) Wt. (lbs)
HR01-15PC Mount Kit for HR2 & CR3 Series Racks, 15", Powder coated 6.25 x 2 x 15.75 22
HR01-17PC Mount Kit for HR2 & CR3 Series Racks, 17", Powder coated 6.25 x 2 x 17.75 23
HR1 Series Storage Box
Part No. Description WxDxH (in) Wt. (lbs)
HR1A-SLB01 HR1 series storage box 21W checker plate 21 x 23.75 x 20.375 45
HR1A-MP01 Mount plate for HR1 series storage box HR1A-SLB01 34 x 24 x 1.25 11
Headache Rack Work Lamp Mounts
Part No. Description WxDxH (in) Wt. (lbs)
HRA-WLKIT Headache Rack Bolt-On Work Lamp Mount Bracket Kit -PAIR 3.75 x 2.47 x 4 0
Low Profile Decks for HR2 & CR3 Series
Part No. Description WxDxH (in) Wt. (lbs)
LPD40 Low Profile Deck for HR2 and CR3 Series Racks 33.5 x 35.3125 x 9.75 29
LPD23 Low Profile Deck for HR2 and CR3 Series Racks 33.5 x 18.3125 x 9.75 29
Mount Kit for LR7 Series Logging Rack
Part No. Description WxDxH (in) Wt. (lbs)
LR01 Mount Kit for LR7 Series Logging Racks 7.25 x 2 x 18.5 55
Light Guards for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-088 Single Light Guard for LR7 Series Logging Rack, upper bolt-on 3.563 x 9.75 x 9.5 2.5
LR7A-DLG Dual Light Guard for LR7 Series Logging Rack, upper 9.6875 x 3.625 x 20.625 5
LR7A-SLG Single Light Guard for LR7 Series Logging Rack, lower 8.125 x 5.75 x 12.1875 2
Tool Holders for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-BRM Broom Holder Bracket for LR7 Series Logging Rack 8 x 3.5 x 6.8125 2
LR7A-SVL Shovel Holder for LR7 Series Logging Rack, bolt-on, 3/16" aluminum 18 x 3 x 2 1
SH03 Shovel Holder Bracket - Bolt On 2.25 x 2.625 x 3 0.4
Chain Tray Perimeters for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-CTP-L Chain Tray Perimeter for LR7 Series Logging Rack, bolt-on, 3/16" aluminum - LEFT 33.6875 x 19.1875 x 6 8
LR7A-CTP-R Chain Tray Perimeter for LR7 Series Logging Rack, bolt-on, 3/16" aluminum - RIGHT 33.6875 x 19.1875 x 6 8
Lights and Housings for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-D4-01 Dual 4" Light Housing for Logging Rack, aluminum, weld-on - fits L&R (lights & wiring extra) 6.125 x 5.125 x 6 2
LR7A-D4-LED LED Light & Wiring Kit for one (1) LR7A-D4-01 Dual 4" Light Housing 0 x 0 x 0 0
LR7A-S4-01 Single 4" Light Housing for Logging Rack, aluminum, weld-on - fits L&R (lights & wiring extra) 6.125 x 5.125 x 6 2
LR7A-S4-LED LED Light & Wiring Kit for one (1) LR7A-S4-01 Single 4" Light Housing 0 x 0 x 0 0
LR7A-TO-01 Tri-Oval Light Housing for Logging Rack, aluminum, weld-on - fits L&R (lights & wiring extra) 4.125 x 4 x 24 4
LR7A-TO-02L Tri-Oval Light Housing for Logging Rack, aluminum, bolt-on - LEFT (lights & wiring extra) 5.625 x 4.438 x 25.5 4.5
LR7A-TO-02R Tri-Oval Light Housing for Logging Rack, aluminum, bolt-on - RIGHT (lights & wiring extra) 5.625 x 4.438 x 25.5 4.5
LR7A-TO-LED LED Light & Wiring Kit for one (1) LR7A-TO Tri-Oval Light Housing 0 x 0 x 0 0
Grab Handle for Logging Rack
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-GH42 Grab Handle for LR7 Series Logging Rack, 42" 2.5 x 3 x 48 6
Window Parts for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-JBW Jail Bar Window Guard for LR7 Series Logging Rack, bolt-on, aluminum 24 x 2 x 38 14
LR7A-JBW-02 Mesh Panel for LR7A-JBW Jail Bar Window Guard, heavy duty expanded mesh, bolt-on, aluminum 30.75 x 2.125 x 38 8
Quad Pull-Out Lights
Part No. Description WxDxH (in) Wt. (lbs)
QPOL-PKG Quad Pull-out Light Housings, LED Lights, Wiring & Slide Tube - Fits Left & Right, Order Two 36.25 x 5.75 x 8.5 11
QPOL-KIT Quad Pull-out Light Housing w/ oval holes & steel slide tube - fits L&R (lights & wiring extra) 0 x 0 x 0 11
Sign Boards for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-SGN-01 Side Sign Board for LR7 Series Logging Rack, bolt-on at side, 1/8" aluminum 9 x 0.125 x 36 4
LR7A-SGN-02 Sign Board for LR7 Series Logging Rack 38.8125 x 0.875 x 7.75 4
LR7A-SGN-03 Sign Board for LR7 Series Logging Rack - High Mount 53.375 x 0.875 x 7.75 4
Logging Rack Storage Box
Part No. Description WxDxH (in) Wt. (lbs)
LR7ASLB01 Logging Rack Storage Box, 24" Wide 24 x 20 x 19.5 29
LR7ASLB02 Logging Rack Storage Box, 32" Wide 32 x 20 x 19.5 29
Load Wrap Holders for Cab Guards
Part No. Description WxDxH (in) Wt. (lbs)
LWH-01 Load Wrap Holder for Cab Guards, bolt-on with lid 22.5 x 5.2 x 4 1
Air Actuated Signs for Cab Guards
Part No. Description WxDxH (in) Wt. (lbs)
ADS-D72 Air "D" Sign with Reflective Red & White 72 x 3 x 46 87
ADS-O72 Air OVERSIZE LOAD Sign - yellow with black letters 72 x 3 x 46 87
ADS-PKIT ADS PLUMBING KIT 0 x 0 x 0 0
Tarp Holders for Cab Guards
Part No. Description WxDxH (in) Wt. (lbs)
TH601616 Tarp Holder 60W16D16H w/ gussets - aluminum 60 x 16 x 16 26
Universal U-Bolt Mount Kit
Part No. Description WxDxH (in) Wt. (lbs)
UB4X18 18IN U-bolt universal mount kit 24 x 2 x 7 21

Cab Guards - CR3 Series

Our CR3 Series 3-compartment Cabinet Racks are built on our industry-leading low-profile steel base platform and integral aluminum I-beam design balancing long-term durability w/ customizable options.

Recommended Mount Kits are: UHD4X15 (aka HR01-15) or the new UB4X18. Compatible w/ new direct-mount steel feet. May be ordered with a Low-Profile Deck.

12" Deep Cabinet Racks
Part No. Description WxDxH (in) Wt. (lbs)
CR400000 Basic Three Door Cabinet Rack with Increased Depth to 12" 82 x 23 x 70 410
CR410200 Cabinet Rack - Standard Oval Lights, 12" Deep 82 x 23 x 70 390
CR410300 Cabinet Rack - Standard Round Lights, 12" Deep 82 x 23 x 70 390
CR30 Square Corner Cabinet Racks
Part No. Description WxDxH (in) Wt. (lbs)
CR300000 Cabinet Rack - Plain 82 x 23 x 70 334
CR300000-14D Basic Three Door Cabinet Rack with Increased Depth to 12" 82 x 23 x 70 390
CR30005J Cabinet Rack - Jailbar Window 41", Deck 82 x 23 x 70 363
CR31 Square Cabinet Racks w/ Round Lights
Part No. Description WxDxH (in) Wt. (lbs)
CR310100 Cabinet Rack - Standard Round Lights 82 x 23 x 70 334
CR310300 Cabinet Rack - All Red Round Lights 82 x 23 x 70 334
CR31 Cabinet Racks w/ Lights & Windows
Part No. Description WxDxH (in) Wt. (lbs)
CR31013J Cabinet Rack - Standard Round Lights, Jailbar Window 39" 82 x 23 x 70 334
CR31043J Cabinet Rack - All Red Oval Lights, Jailbar Window 39" 82 x 23 x 70 334
CR31 Square Cabinet Racks w/ Oval Lights
Part No. Description WxDxH (in) Wt. (lbs)
CR310200 Cabinet Rack - Standard Oval Lights 82 x 23 x 70 334
CR310400 Cabinet Rack - All Red Oval Lights 82 x 23 x 70 334
CR32 Round Corner Cabinet Racks
Part No. Description WxDxH (in) Wt. (lbs)
CR320100 Cabinet Rack - Standard Round Lights 82 x 23 x 70 334
CR320200 Cabinet Rack - Standard Oval Lights 82 x 23 x 70 334
CR320300 Cabinet Rack - All Red Round Lights 82 x 23 x 70 334
CR3 Cabinet Racks for Hyd Tanks
Part No. Description WxDxH (in) Wt. (lbs)
CR32M400 Cabinet Rack - All Red Oval Lights, Hydraulic Tank Recess 82 x 23 x 70 334
CR30M000 Cabinet Rack - Plain, Hydraulic Tank Recess 82 x 23 x 70 363
CR30M03J Cabinet Rack - Jailbar Window 39", Hydraulic Tank Recess 82 x 23 x 70 363
CR31M100 Cabinet Rack - Standard Round Lights, Hydraulic Tank Recess 82 x 23 x 70 334
CR31M200 Cabinet Rack - Standard Oval Lights, Hydraulic Tank Recess 82 x 23 x 70 334
CR31S200 Cabinet Rack - Standard Oval Lights, Hydraulic Tank Recess (Small) 82 x 23 x 70 334
CR32T200 Cabinet Rack - Standard Oval Lights, Hydraulic Tank Recess (Tall) 82 x 23 x 70 334
Roll-up Door Cabinet Racks
Part No. Description WxDxH (in) Wt. (lbs)
RR1100 Roll-up Door Cabinet Rack 82 x 23.25 x 70.25 340

Cab Guards - HR1 Series

Our HR1 Series Racks are 100% lightweight aluminum with a proprietary D-tube perimeter and structural I-Beam feet which are reinforced in critical areas for additional strength.

Recommended Mount Kits are the UHD4X15 (aka HR01-15) or the new UB4X18.

HR100000 Headache Rack
Part No. Description WxDxH (in) Wt. (lbs)
HR100000 Headache Rack - Plain 82.5 x 24.5 x 68 161
HR10 Headache Racks w/ Jailbar Windows
Part No. Description WxDxH (in) Wt. (lbs)
HR10003J Headache Rack - Jailbar Window 39" 82.5 x 24.5 x 68 175
HR10006J Headache Rack - Jailbar Window 42" 82.5 x 24.5 x 68 175
HR10023J Headache Rack - Jailbar Window 39", Standard Oval Lights 82.5 x 24.5 x 68 180
HR10 w/ Mesh & Open Windows
Part No. Description WxDxH (in) Wt. (lbs)
HR10003M Headache Rack - Mesh Window 39" 82.5 x 24.5 x 68 175
HR10006M Headache Rack - Mesh Window 42" 82.5 x 24.5 x 68 175
HR110000 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR110000 Headache Rack - Chain Tray and 2x Chain Hangers 82.5 x 24.5 x 68 178
HR130000 Headache Rack - Chain Tray and 3x Chain Hangers 82.5 x 24.5 x 68 195
HR11 w/ Jailbar Windows
Part No. Description WxDxH (in) Wt. (lbs)
HR11003J Headache Rack - Chain Tray and 2x Chain Hangers, Jailbar Window 39" 82.5 x 24.5 x 68 188
HR11006J Headache Rack - Chain Tray and 2x Chain Hangers, Jailbar Window 42" 82.5 x 24.5 x 68 188
HR11023J Headache Rack - Chain Tray and 2x Chain Hangers, Jailbar Window 39", Standard Oval Lights 82.5 x 24.5 x 68 188
HR11 w/ Mesh & Open Windows
Part No. Description WxDxH (in) Wt. (lbs)
HR11003M Headache Rack - Chain Tray and 2x Chain Hangers, Mesh Window 39" 82.5 x 24.5 x 68 191
HR11006F Headache Rack - Chain Tray and 2x Chain Hangers, Open Window 42" 82.5 x 24.5 x 68 178
HR11006M Headache Rack - Chain Tray and 2x Chain Hangers, Mesh Window 42" 82.5 x 24.5 x 68 191
HR12 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR120000 Headache Rack - Side Chain Trays and 2x Chain Hangers 82.5 x 24.5 x 68 182
HR12003J Headache Rack - Side Chain Trays and 2x Chain Hangers, Jailbar Window 39" 82.5 x 24.5 x 68 192
HR12003M Headache Rack - Side Chain Trays and 2x Chain Hangers, Mesh Window 39" 82.5 x 24.5 x 68 195
HR12006J Headache Rack - Side Chain Trays and 2x Chain Hangers, Jailbar Window 42" 82.5 x 24.5 x 68 192
HR15 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR150000 Headache Rack - Hanging Chain Buckets and 2x Chain Hangers 82.5 x 24.5 x 68 195
HR15003J Headache Rack - Hanging Chain Buckets and 2x Chain Hangers, Jailbar Window 39" 82.5 x 24.5 x 68 205
HR15006J Headache Rack - Hanging Chain Buckets and 2x Chain Hangers, Jailbar Window 42" 82.5 x 24.5 x 68 205
HR10 Series Racks for Hyd Tanks
Part No. Description WxDxH (in) Wt. (lbs)
HR15M000 Headache Rack - Hanging Chain Buckets and 2x Chain Hangers, Hydraulic Tank Recess 82.5 x 24.5 x 68 193
HR10M03J Headache Rack - Jailbar Window 39", Hydraulic Tank Recess 82.5 x 24.5 x 68 185
HR12M03J Headache Rack - Side Chain Trays and 2x Chain Hangers, Jailbar Window 39", Hydraulic Tank Recess 82.5 x 24.5 x 68 206
HR15M03J Headache Rack - Hanging Chain Buckets and Chain Hangers, Jailbar Window 39", Hydraulic Tank Recess 82.5 x 24.5 x 68 198
HR15S03J Headache Rack - Hanging Chain Buckets and Chain Hangers, Jailbar Window 39", Hydraulic Tank Recess (Small) 82.5 x 24.5 x 68 179
HR15T06J Headache Rack - Hanging Chain Buckets and Chain Hangers, Jailbar Window 42", Hydraulic Tank Recess (Tall) 82.5 x 24.5 x 68 179

Cab Guards - HR2 Series

Our HR2 Series Racks feature an one-piece D-tube perimeter exclusive to ACE and 6" structural I-Beams are mounted to low-profile, powder-coated steel feet for extra strength and increased clearance.

Recommended Mount Kits are the UHD4X15 (aka HR01-15) or the new UB4X18. This series is compatible with new direct-mount steel feet & may be ordered with a Low-Profile Deck.

HR20 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR200000 Headache Rack - Plain 82.5 x 23 x 70 200
HR200000-94W Headache Rack - Plain, Ultra wide 94" 94 x 23 x 70 212
HR20002J Headache Rack - Jailbar Window 38" 82.5 x 23 x 70 200
HR20M23J Headache Rack - Jailbar Window 39", Hydraulic Tank Recess 82.5 x 23 x 70 200
HR20 Racks w/ Lights
Part No. Description WxDxH (in) Wt. (lbs)
HR20035J Headache Rack - Jailbar Window 41", All Red Round Lights 82.5 x 23 x 70 230
HR200400 Headache Rack - All Red Oval Lights 82.5 x 23 x 70 200
HR2 Series Racks for HYD Tanks
Part No. Description WxDxH (in) Wt. (lbs)
HR20M000 Headache Rack - Hydraulic Tank Recess 82.5 x 23 x 70 200
HR20M000-94W Headache Rack - Hydraulic Tank Recess, 94in Width 94.5 x 23 x 70 200
HR21 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR210000 Headache Rack - Chain Tray and 2x Chain Hangers 82.5 x 23 x 70 220
HR21003J Headache Rack - Chain Tray and 2x Chain Hangers, Jailbar Window 39" 82.5 x 23 x 70 240
HR21013J Headache Rack - Chain Tray and 2x Chain Hangers, Jailbar Window 39", Standard Round Lights 82.5 x 23 x 70 240
HR210400 Headache Rack - Chain Tray and 2x Chain Hangers, All Red Oval Lights 82.5 x 23 x 70 230
HR230000 Headache Rack - Chain Tray and 3x Chain Hangers 82.5 x 23 x 70 244
HR22 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR220000 Headache Rack - Side Chain Trays and 2x Chain Hangers 82.5 x 23 x 70 241
HR22002M Headache Rack - Side Chain Trays and 2x Chain Hangers, Mesh Window 38" 82.5 x 23 x 70 241
HR22003J Headache Rack - Side Chain Trays and 2x Chain Hangers, Jailbar Window 39" 82.5 x 23 x 70 241
HR220200 Headache Rack - Side Chain Trays and 2x Chain Hangers, Standard Oval Lights 82.5 x 23 x 70 235
HR25 Headache Racks
Part No. Description WxDxH (in) Wt. (lbs)
HR250000 Headache Rack - Hanging Chain Buckets and 2x Chain Hangers 82.5 x 23 x 70 250
HR 2 Series Racks w/ Centre Cabinets
Part No. Description WxDxH (in) Wt. (lbs)
HR2600SC Headache Rack - Recessed Chain Tubs and 2x Chain Hangers, Center Cabinet 82.5 x 23 x 70 255
HR2200SC Headache Rack - Side Chain Trays and 2x Chain Hangers, Center Cabinet 82.5 x 23 x 70 260
HR26000R Headache Rack - 3x Recessed Chain Tubs and 3x Chain Hangers 82.5 x 23 x 70 265
HR2600XC Headache Rack - Recessed Chain Tubs and 2x Chain Hangers, Center Cabinet 82.5 x 23 x 70 255
HR27000R Headache Rack - Centre Recessed Chain Tub and 3x Chain Hangers 82.5 x 23 x 70 265

Cab Guards - Hydraulic

Rectangular, Aluminum Tanks designed to be used behind the cab with ACE Cab Guards & Steel Cradle (ordered separately). From 3/16” thick checker plate standard (smooth option available).

Tanks include suction & return fittings, vented cap, temp/sight gauge & stainless steel straps with rubber backing for mounting.

Cab Guard Hydraulic Tanks & Cradle
Part No. Description WxDxH (in) Wt. (lbs)
HYD30CP Hydraulic Oil Reservoir, 30USG, checker plain rectangular configuration 23 x 24 x 14 60
HYD40CP Hydraulic Oil Reservoir, 40USG, checker plain rectangular configuration 23 x 24 x 18.25 70
HYD50CP Hydraulic Oil Reservoir, 50USG, checker plain rectangular configuration 23 x 24 x 22.5 79
HYD50M-CP Hydraulic Oil Reservoir, Reduced Depth, Tall 50USG, checkerplate plain rectangular configuration 23 x 17 x 31 79
HYD50M-SM Hydraulic Oil Reservoir, Reduced Depth, Tall 50USG, checkerplate plain rectangular configuration 23 x 17 x 31 79
HYD60CP Hydraulic Oil Reservoir, 60USG, checker plain rectangular configuration 23 x 24 x 27 89
HYD70CP Hydraulic Oil Reservoir, 70USG, checker plain rectangular configuration 23 x 24 x 31.25 100
HYD70SM Hydraulic Oil Reservoir, 70USG, checker plain rectangular configuration 23 x 24 x 31.25 100
HYD80CP Hydraulic Oil Reservoir, 80USG, checker plain rectangular configuration 23 x 24 x 35.75 110
HYDCRDL Hydraulic Tank Cradle - supports hydraulic tank, steel - powder coated 33.5 x 25.5 x 2 41

Cab Guards - LR7 Series

Our LR7 and LR6 Series Aluminum Logging Racks are built around an HD webbing + tube design w/ steel reinforced U-bolt mounting areas. Multiple options for windows, decks, upper ears and accessories.

An LR01 Mount Kit consisting of 4 U-Bolts w/ tie bars, hardware & isolation strips is included with each logging rack.

LR6 Racks w/ STD Ears, Centre Deck Only
Part No. Description WxDxH (in) Wt. (lbs)
LR6100 Low-Profile Logging Rack 96W94H STD Ears w/ Middle Bar, Centre Deck Only and Mount Kit 96 x 24 x 94 475
LR6102 Low-Profile Logging Rack 96W94H STD Ears w/ Bar, Centre Deck, Jailbar Window w/ Mesh, and Mount Kit 96 x 24 x 94 475
LR6 Racks w/ STD Ears, Tapered Deck
Part No. Description WxDxH (in) Wt. (lbs)
LR6110 Low-Profile Logging Rack 96W94H STD Ears w/ Middle Bar,Tapered Deck and Mount Kit 96 x 24 x 94 475
LR6112 Low-Profile Logging Rack 96W94H STD Ears w/ Bar,Tapered Deck, Jailbar Window w/ Mesh, and Mount Kit 96 x 24 x 94 475
LR6 Racks w/ STD Ears, Full Deck
Part No. Description WxDxH (in) Wt. (lbs)
LR6120 Low-Profile Logging Rack 96W94H STD Ears w/ Middle Bar, Full Deck and Mount Kit 96 x 24 x 94 475
LR6122 Low-Profile Logging Rack 96W94H STD Ears w/ Bar, Full Deck, Jailbar Window w/ Mesh, and Mount Kit 96 x 24 x 94 475
LR7 Logging Rack with No Ears
Part No. Description WxDxH (in) Wt. (lbs)
LR7010 Full Web Logging Rack 100W77H, Tapered Deck and Mount Kit 100.5 x 39.5 x 77.25 510
LR7 Logging Racks w/ HD Ears, Tapered Deck
Part No. Description WxDxH (in) Wt. (lbs)
LR7312 Full Web Logging Rack 100W95H HD Ears, Tapered Deck, Jailbar Window w/ Mesh, and Mount Kit 100 x 39.5 x 95 520
LR7310 Full Web Logging Rack 100W95H HD Ears, Tapered Deck and Mount Kit 100.5 x 39.5 x 95 510
LR7314 Full Web Logging Rack 100W95H HD Ears, Tapered Deck, Half Backboard Mesh and Mount Kit 100 x 42 x 95 550
LR7 Logging Racks w/ HD Ears, Full Deck
Part No. Description WxDxH (in) Wt. (lbs)
LR7320 Full Web Logging Rack 100W95H HD Ears, Full Deck and Mount Kit 100.5 x 41.25 x 95 510
LR7321 Full Web Logging Rack 100W95H HD Ears, Full Deck, Jailbar Window and Mount Kit 100 x 42 x 95 550
LR7324 Full Web Logging Rack 100W95H HD Ears, Full Deck, Half Backboard Mesh and Mount Kit 100 x 42 x 95 550
AB spec Rig-up Pkg for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-ABPKG Alberta Spec Logging Rack Accessory Package 0 x 0 x 0 0
SK spec Rig-up Pkg for Logging Racks
Part No. Description WxDxH (in) Wt. (lbs)
LR7A-SKPKG Saskatchewan Spec Logging Rack Accessory Package 116.75 x 39.5 x 95 0

Fender Mounting - Front

Heavy Duty mounting solutions for Aluminum Checker plate Fenders with universal and model/suspension-specific options.

Brackets are galvanized when possible or powder coated to create maximum durability. Multiple brackets may be required for certain Fender-mounting applications.

Front Fender BRKT - PB Low Air Leaf - fits L&R
Part No. Description WxDxH (in) Wt. (lbs)
F328 Peterbilt Low Air Leaf Front Fender Bracket - tube style - fits L&R 30.625 x 4.75 x 3 16
Powder Coated Front Fender Brackets
Part No. Description WxDxH (in) Wt. (lbs)
F330L Std. Front Fender Bracket, powder coated - LEFT 30.375 x 3 x 7 10
F330R Std. Front Fender Bracket, powder coated - RIGHT 30.375 x 3 x 7 10
F330WT-L Std. Front Fender Bracket for Wide Track, powder coated - LEFT 33.375 x 3 x 7 12
F330WT-R Std. Front Fender Bracket for Wide Track, powder coated - RIGHT 33.375 x 3 x 7 12
Front Fender Brackets for Airliner
Part No. Description WxDxH (in) Wt. (lbs)
FBF-AL-L-G Fender Bracket, FRONT - WS & FL Airliner standard width, LEFT, galvanized 30 x 10.5 x 8 35
FBF-AL-R-G Fender Bracket, FRONT - WS & FL Airliner standard width, RIGHT, galvanized 30 x 10.5 x 8 35
Front Fender Brackets for Neway ADZ
Part No. Description WxDxH (in) Wt. (lbs)
FBF-NE-L Fender Bracket, FRONT, Neway ADZ, standard width, Left, powder coat black 28.625 x 2 x 5.813 9
FBF-NE-R Fender Bracket, FRONT, Neway ADZ, standard width, Right, powder coat black 28.625 x 2 x 5.813 9
FBF-NE-WT-L Fender Bracket, FRONT, Neway ADZ, Wide Track, Left 32 x 2 x 6.813 10
FBF-NE-WT-R Fender Bracket, FRONT, Neway ADZ, Wide Track, Right 32 x 2 x 6.813 10

Fender Mounting - Rear

Heavy Duty mounting solutions for Aluminum Checker plate Fenders with universal and model/suspension-specific options.

Brackets are galvanized when possible or powder coated to create maximum durability. Multiple brackets may be required for certain Fender-mounting applications.

Fixed STD Width Rear Fender Brackets
Part No. Description WxDxH (in) Wt. (lbs)
F331L Std. Rear Fender Bracket, galvanized - LEFT 30.5 x 2.5 x 14.125 12
F331HD-L HD Rear Fender Bracket, galvanized - LEFT 30.5 x 2.5 x 14.125 21
F331HD-R HD Rear Fender Bracket, galvanized - RIGHT 30.5 x 2.5 x 14.125 21
F331L-PC Std. Rear Fender Bracket, powder coated - LEFT 30.5 x 2.5 x 14.125 12
F331R Std. Rear Fender Bracket, galvanized - RIGHT 30.5 x 2.5 x 14.125 12
F331R-PC Std. Rear Fender Bracket, powder coated - RIGHT 30.5 x 2.5 x 14.125 12
Fixed Wide-Track Rear Fender Brackets
Part No. Description WxDxH (in) Wt. (lbs)
F332WT-L-G Std. Rear Fender Bracket for Wide Track, galvanized - LEFT 32.875 x 2 x 14.125 13
F332WT-HD-L HD Rear Fender Bracket for Wide Track, galvanized - LEFT 32.875 x 2 x 14.125 24
F332WT-HD-R HD Rear Fender Bracket for Wide Track, galvanized - RIGHT 32.875 x 2 x 14.125 24
F332WT-PC-L Std. Rear Fender Bracket for Wide Track, powder coated - LEFT 32.875 x 2 x 14.125 13
F332WT-PC-R Std. Rear Fender Bracket for Wide Track, powder coated - RIGHT 32.875 x 2 x 14.125 13
F332WT-R-G Std. Rear Fender Bracket for Wide Track, galvanized - RIGHT 32.875 x 2 x 14.125 13
Adjustable Rear Fender Brackets
Part No. Description WxDxH (in) Wt. (lbs)
F333L Adjustable Rear Fender Bracket, galvanized - LEFT 28.875 x 5.5 x 9.125 11
F333R Adjustable Rear Fender Bracket, galvanized - RIGHT 28.875 x 5.5 x 9.125 11
F333WT-L Adjustable Rear Fender Bracket, galvanized - LEFT 31.875 x 5.5 x 9.5625 15
F333WT-R Adjustable Rear Fender Bracket, galvanized - RIGHT 31.875 x 5.5 x 9.5625 15
Rear Fender Brackets for Airliner
Part No. Description WxDxH (in) Wt. (lbs)
F334L Rear Fender Bracket for WS&FL Airliner - LEFT 28.438 x 2.25 x 14.375 14
F334R Rear Fender Bracket for WS&FL Airliner - RIGHT 28.438 x 2.25 x 14.375 14
Rear Fender Brackets for Airliner
Part No. Description WxDxH (in) Wt. (lbs)
FBR-AL-L Rear Fender Bracket for WS&FL Airliner - LEFT 30 x 2.5 x 15.625 20.3
FBR-AL-L-G Rear Fender Bracket for WS&FL Airliner - LEFT, galvanized 30 x 2.5 x 15.625 20.3
FBR-AL-R Rear Fender Bracket for WS&FL Airliner - RIGHT 30 x 2.5 x 15.625 20.3
FBR-AL-R-G Rear Fender Bracket for WS&FL Airliner - RIGHT, galvanized 30 x 2.5 x 15.625 20.3
Rear Fender Brackets for Wide-Track Neway
Part No. Description WxDxH (in) Wt. (lbs)
FBR-NE-WT-L Fender Bracket, REAR, Neway ADZ, Wide Track, Left 31.625 x 2.188 x 15.375 19.3
FBR-NE-L Fender Bracket, REAR, Neway ADZ, Left 29 x 2.2 x 15.5 18.3
FBR-NE-R Fender Bracket, REAR, Neway ADZ, Right 29 x 2.2 x 15.5 18.3
FBR-NE-WT-R Fender Bracket, REAR, Neway ADZ, Wide Track, Right 31.625 x 2.188 x 15.375 19.3

Fenders - Accessories

Fender Flange Covers
Part No. Description WxDxH (in) Wt. (lbs)
F340-55-L Fender Flange for F301-55, fills fender to frame gap, 1/8" checker - LEFT (DRV side) - trim to fit 3.75 x 55 x 7 4
F340-110-L Fender Flange for F301-110, fills fender to frame gap, 1/8" checker - LEFT (DRV side) - trim to fit 3.75 x 110 x 7 8
F340-110-R Fender Flange for F301-110, fills fender to frame gap, 1/8" checker - RIGHT (PAS side) - trim to fit 3.75 x 110 x 7 8
F340-55-R Fender Flange for F301-55, fills fender to frame gap, 1/8" checker - RIGHT (PAS side) - trim to fit 3.75 x 55 x 7 4
F340WT-110-L Fender Flange for F301-110, fills fender to frame gap, 1/8" checker - LEFT (DRV side) - trim to fit 7 x 110 x 7 12
F340WT-110-R Fender Flange for F301-110, fills fender to frame gap, 1/8" checker - RIGHT (PAS side) - trim to fit 7 x 110 x 7 12
F340WT-55-L Fender Flange for F301-55, fills fender to frame gap, 1/8" checker - LEFT (DRV side) - trim to fit 7 x 55 x 7 6
F340WT-55-R Fender Flange for F301-55, fills fender to frame gap, 1/8" checker - RIGHT (PAS side) - trim to fit 7 x 55 x 7 6

Fenders - Tandem Half

Our standard Fenders are 3/16" Checker plate Aluminum with Huck-bolted gussets and optional stiffeners for any HD application. ACE carries many model/suspension-specific mounting options.

When ordering: Combo Tire Chain Hanger/Fender Bracket may be used as a Front Bracket. You will need one Rear Bracket per Fender for Tandem (Half) Fenders.

MD 1/8" Aluminum Tandem Half Fenders
Part No. Description WxDxH (in) Wt. (lbs)
F300-55 Tandem Half Fender 55"L, 1/8" checker - HIGHWAY USE ONLY 26 x 55 x 9 22
HD 3/16" Aluminum Tandem Half Fenders
Part No. Description WxDxH (in) Wt. (lbs)
F301-55 Tandem Half Fender 55"L, 3/16" checker aluminum 26 x 55 x 9 33
F301-55-CS-MFP Tandem Half Fender 55"Lx26"W, 3/16" checker w/ center stiffener and end cap 26 x 55 x 9 34
F301-55-DSS Tandem Half Fender 55"Lx26"W, 3/16" checker w/ side stiffener for driver side 26 x 55 x 9 35
F301-55-PSS Tandem Half Fender 55"Lx26"W, 3/16" checker w/ side stiffener for passenger side 26 x 55 x 9 35
F301-55-SCS Tandem Half Fender 55"Lx26"W, 3/16" checker w/ side and centre stiffeners 26 x 55 x 9 35
F301-55-SM Tandem Half Fender 55"Lx26"W, 3/16" smooth aluminum 26 x 55 x 9 32
F301-55-SS Tandem Half Fender 55"Lx26"W, 3/16" checker w/ side stiffeners 26 x 55 x 9 32

Fenders - Tridem

Our standard Fenders are 3/16" Checker plate Aluminum with Huck-bolted gussets and optional stiffeners for any HD application. ACE carries many model/suspension-specific mounting options.

When ordering: Combo Tire Chain Hanger/Fender Bracket may be used as a Front Bracket. You will need two Rear Brackets per Fender for Tridem (Half) Fenders.

HD 3/16" Aluminum Tri-Drive Half Fenders
Part No. Description WxDxH (in) Wt. (lbs)
F301-110 Tridem 2/3rd Fender 110"Lx26"W, 3/16" checker 26 x 110 x 9 70
F301-110-DSS Tridem 2/3rd Fender 110"Lx26"W, 3/16" checker w/ side stiffener for driver side 26 x 110 x 9 58
F301-110-PSS Tridem 2/3rd Fender 110"Lx26"W, 3/16" checker w/ side stiffener for passenger side 26 x 110 x 9 58
F301-110-SS Tridem 2/3rd Fender 110"Lx26"W, 3/16" checker w/ stiffeners both sides 26 x 110 x 9 60

OEM - Fender Mounting

Rear Fender Brackets for Wide-Track Airliner
Part No. Description WxDxH (in) Wt. (lbs)
FBR-AL01-WT-L-G Fender BRACKET Rear for WS&FL Airliner High 5th Wheel wide track LEFT galvanized 32.875 x 10.5 x 13.8125 32
FBR-AL01-WT-R-G Fender BRACKET Rear for WS&FL Airliner High 5th Wheel wide track RIGHT galvanized 32.875 x 10.5 x 13.8125 32

Parts & Accessories - ANTI-SIPHONS FTA

Measurements are from the Inside Diameter (ID) of the Fuel Tank Neck. Anti siphons are designed to fit male threaded aluminum or steel fill necks.

Always confirm you filler neck ID size and check your cap. Many Locking Diesel Fuel Caps are not compatible to use with a fuel fill neck that has an Anti-Siphon installed.

Reefer & MD Fuel Tank Anti Siphons
Part No. Description
FTA-187-75 Reefer & MD Anti siphon w/ 1.875" Filler neck, & large tab 3 3/4" from top Note - does not work with locking fuel cap
Freightliner Fuel Tank Anti Siphon
Part No. Description
FTA-225-7 Freightliner Anti siphon w/ 2.25" Filler neck, & large tabs at 3/4" & 2 3/4" from top
FTA-2-7 Freightliner Anti siphon w/ 2" Filler neck, & 8 small tabs around top large tab 3 7/8" from top Note - does not work with locking fuel cap
Volvo, Mack, International Fuel Tank Anti Siphons
Part No. Description
FTA-25-675 Volvo, Mack Anti siphon w/ 2.5" Filler neck, & large tab 3 3/4" from top
FTA-3-7 Volvo, Mack Anti siphon w/ 3" Filler neck, & large tab 3 3/4" from top
Kenworth Fuel Tank Anti Siphons
Part No. Description
FTA-25-7 Kenworth Anti siphon w/ 2.5" Filler neck, & large tabs at 1/2" & 2 3/4" from top Note - does not work with locking fuel cap
FTA-2-7K Kenworth Anti siphon w/ 2" Filler neck, & 8 small tabs around top large tab at Note - does not work with locking fuel cap
4" Filler Neck Tank Anti Siphons
Part No. Description
FTA-4-9 Anti siphon w/ 4" Filler neck, & large tab 4 1/2" from top
Peterbilt Fuel Tank Anti Siphons
Part No. Description
FTA-P-67 Peterbilt Anti siphon w/ installation kit & allen wrench 2.5" ID Fill Neck

Parts & Accessories - CAPS FTA

All Caps are Female Threaded unless otherwise noted, and are for diesel fuel tanks. Caps fit aluminum tanks (unless noted for steel).

Always verify ID filler neck size. Non Vented Caps must be used with Vented Tanks. Vented Caps may be used with Non-Vented or Vented Tanks.

Reefer trailer, Int MD Truck 2.0" ID Fuel Cap
Part No. Description
FTA-C-02 LOCKING Cap Assembly Alum 2.0”- 11.5 NPSH Threaded for 2” SCH 40/80 neck, (ID of Cap 2.25”) Features 220°F Thermal Relief, incl. 8.00” Chain & 6.50” Bail, W/ 'DIESEL FUEL ONLY'. Fuel Tank must be Vented.
FTA-C-08 NON-LOCKING  Cap Assembly Brass 2.0”- 11.5 NPSH Threaded for 2" SCH 40/80 neck (ID of Cap 2.25") Features 190°F Thermal Relief, 3 Lug, incl. 8.00” Chain & 6.50” Bail, W/ 'NON Vented & MICH FLEET'
FTA-C-91A NON-LOCKING Cap Assembly Alum 2.0-11.5 NPSH (ID of Cap 2.25") Full Function Vented,  255°F Thermal W/ Pressure Relief, incl. 6.0” Ball Chain & 4.5” Bail, W/ 'DIESEL FUEL ONLY'
FTA-C-98 NON-LOCKING Cap Assembly Alum 2.0”- 11.5 NPSH Threaded for 2" SCH 40/80 neck (ID of Cap 2.25") 190°F Thermal Relief, incl. 3 Lug, 8.00” Chain & 6.50” Bail, W/ 'DIESEL FUEL ONLY'
Freightliner M2 Fuel Caps 2.5 ID
Part No. Description
FTA-C-13 LOCKING Cap Assembly Alum M-2 2.5”- 8 UN Triple Lead, (ID of Cap 2.38”) 220°F Thermal Relief, incl, 8.00” Chain & 6.50” Bail, W/ 'DIESEL FUEL ONLY'
FTA-C-12 NON-LOCKING Cap Assembly Alum M-2 2.5”- 8 UN Triple Lead, (ID of Cap 2.38”) 220°F Thermal Relief, incl, 8.00” Chain & 6.50” Bail, W/ 'DIESEL FUEL ONLY'
Kenworth 3.5-5.5 NS Caps
Part No. Description
FTA-C-442L Kenworth LOCKING, Non-vented, Cap Assembly Alum 3.5”- 5.5 NS, (ID of Cap 3.375"), Solid, 8.0” Chain & 6.50” Bail W/ 'ULTRA LOW SULFUR DIESEL FUEL'
FTA-C-314 Kenworth NON-LOCKING, Non-vented Cap Assembly Alum 3.5”- 5.5 NS, (ID of Cap 3.375"), Pressure Relief 8.0” Chain & 6.50” Bail W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-442 Kenworth NON-LOCKING, Non-vented, Cap Assembly Alum 3.5”- 5.5 NS, (ID of Cap 3.375"), Solid, 8.0” Chain & 6.50” Bail W/ 'ULTRA LOW SULFUR DIESEL FUEL'
FTA-C-50 KENWORTH LOCKING, Full Function Vented Cap Assembly Alum 3.5”- 5.5 NS, (ID of Cap 2.38”) Features 190°F Thermal Relief, 8.00” Chain & 6.50” Bail, W/ 'DIESEL ONLY KEEP CLEAN & Vented CAP'
FTA-C-81 KENWORTH NON-LOCKING, Full Function Vented Cap Assembly Alum 3.5”- 5.5 NS, (ID of Cap 3.375”) Features 190°F Thermal Relief, 8.00” Chain & 6.50” Bail, W/ 'DIESEL ONLY KEEP CLEAN & Vented CAP'
FTA-C-97 Kenworth LOCKING Non-vented Cap Assembly Alum 3.5”- 5.5 NS Features 255°F Thermal Relief, 12.00” Chain & 6.50” Bail, W/ 'DIESEL ONLY KEEP CLEAN'
4"Fuel Caps - Logging/Dump Trucks
Part No. Description
FTA-C-64 LOCKING, Full Function Vented Cap Assembly Alum 4.0-8 NPSM thread, (ID of Cap 4.35”) Features 255°F Thermal W/ Pressure Relief, 12.00” Chain & 8.35” Bail, W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-01 NON-LOCKING, Full Function Vented Cap Assembly Alum 4.0-8 NPSM thread, (ID of Cap 4.35”) Features 255°F Thermal W/ Pressure Relief, 12.00” Chain & 8.35” Bail, W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-04 LOCKING Non-vented Cap Assembly Alum 4.0-8 NPSL thread, (ID of Cap 4.35”) Features 190°F Thermal Relief, 12.00” Chain & 8.35” Bail W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-15 LOCKING Non-vented Cap Assembly Alum 4.0-8 NPSL thread, (ID of Cap 4.35”),Pressure Relief with 12.00” Chain & 8.35” / 'DIESEL ONLY KEEP CLEAN'
FTA-C-22 NON-LOCKING, Full Function Vented Cap Assembly Alum 4.0-8 NPSL thread, (ID of Cap 4.35”) Features 255°F Thermal W/ Pressure Relief, incl. 12.00” Chain & 8.35” Bail, W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-23 LOCKING, Full Function Vented Cap Assembly Alum 4.0-8 NPSL thread, (ID of Cap 4.35”) Features 255°F Thermal W/ Pressure Relief, 12.00” Chain & 8.35” Bail, W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-90 NON-LOCKING, Non-vented Cap Assembly Alum 4.0-8 NPSL thread, (ID of Cap 4.35") Features 190°F Thermal Relief, 12.00” Chain & 8.35” / 'DIESEL ONLY KEEP CLEAN'
Peterbilt Lever Style Locking Fuel Cap
Part No. Description
FTA-C-67-P Peterbilt LOCKING lever style, Non-vented Cap Assembly Alum 4.0” for 4” SCH 40/80 neck, & Pressure Relief, 8.00” Chain & 6.50” Bail
FTA-C-68-P Peterbilt NON-LOCKING lever style, Non-vented Cap Assembly Alum 4.0” for 4” SCH 40/80 neck, & Pressure Relief, 8.00” Chain & 6.50” Bail
Volvo, Mack, Int Caps - Diesel Tanks Not Labelled Low Sulfur
Part No. Description
FTA-C-69 LOCKING  Non-vented Cap Assembly Alum 3.0”- 8 NPSL, (ID of Cap 3.375”), Pressure Relief 8.00” Chain & 6.50” Bail,  W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-19 NON-LOCKING Full Function Vented Cap Assembly Alum 3.0”- 8 NPSL, (ID of Cap 3.375”) Features 255°F Thermal W/ Pressure Relief, 8.0” Chain & 8.35” Bail,  W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-28 NON-LOCKING, Non-vented Cap Assembly Alum 3.0”- 8 NPSL, (ID of Cap 3.375”) 8.0” Chain & 8.00” Bail, W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-80 LOCKING Full Function Vented Cap Assembly Alum 3.0”- 8 NPSL, (ID of Cap 3.375”) Features 190°F Thermal W/ Pressure Relief, 8.0” Chain & 6.50” Bail,  W/ 'DIESEL ONLY KEEP CLEAN'
FTA-C-87 NON-LOCKING Non-vented Cap Assembly Alum 3.0”- 8 NPSL, (ID of Cap 3.375”) Features 190°F Thermal W/ Pressure Relief, 8.0” Chain & 6.50” Bail,  W/ 'DIESEL ONLY KEEP CLEAN'
Volvo Low Sulfur Labelled Tank Cap
Part No. Description
FTA-C-722 NON-LOCKING Non Vented Cap Assembly Alum 3”- 8 UN Triple Lead, (ID of Cap 2.88”) Solid,  6.50” Chain & 6.50” Bail, No Logo,  W/ 'ULTRA LOW SULFUR DIESEL FUEL ONLY' ID under cap  FTA-C-722
FTA-C-722L LOCKING Non Vented Cap Assembly Alum 3"- 8 UN Triple Lead, (ID of Cap 2.88") Solid,  6.50" Chain & 6.50" Bail, No Logo,  W/ 'ULTRA LOW SULFUR DIESEL FUEL ONLY' ID under cap  FTA-C-722
FTA-C-76 Low Sulfur, LOCKING, Non-vented Cap assembly 3"- 8 UNNS 8.00” Chain & 6.50” Bail,  W/ 'ULTRA LOW SULFER DIESEL FUEL ONLY'
Borg Warner Steel Tank Fuel Caps
Part No. Description
FTA-C-74 Borg Warner LOCKING, Non-vented, Steel Tank Fuel Cap Assembly Alum 2.5-8 UN (ID of Cap 4.35”) Features  220°F Thermal Relief, incl. 8.00” Chain & 6.50” Bail,  W/ 'DIESEL FUEL ONLY'
FTA-C-14-03 Borg Warner LOCKING, Vented, Steel Tank Fuel Cap Assembly Alum 2.5-8 UN (ID of Cap 4.35”) Features  255°F Thermal Relief, incl. 12.00” Chain & 4.50” Bail,  W/ 'DIESEL FUEL ONLY'
Freightliner 1/4-Turn Fuel Caps
Part No. Description
FTA-C-92 Freightliners 1/4 Turn NON-LOCKING Non-vented Cap Assembly Features  220°F Thermal Relief, incl. 8.00” Chain & 6.50” Bail,  W/ 'DIESEL FUEL ONLY' & No Logo
FTA-C-93 Freightliners 1/4 Turn LOCKING Non-vented Cap Assembly Features  220°F Thermal Relief, incl. 8.00” Chain & 6.50” Bail,  W/ 'DIESEL FUEL ONLY'  & No Logo

Parts & Accessories - HYDRAULIC TANKS FTA

Premium Lightweight Aluminum tanks in round, saddle mount and upright, rectangular orientations to fit a variety of applications and layouts.

Ships with required hardware for frame mounting and includes Filler Breather Cap with Strainer, Sight Level Gauge w/Temperature indicator, and multiple ports with sizing options.

Hydraulic Tank Components
Part No. Description
FTA-BCA-32 LENZ Filler Breather Cap with Nylon Strainer 57XL-40N for Saddle-Mount & Upright Hyd Tanks Keeps Fluids Clean and Prolongs System Life with 40 Micron, 4" Nylon Strainer
FTA-SG-46 LENZ Sight Level Gauge with Temp Indicator for Saddle-Mount & Upright Hyd Tanks 5" Transparent Sight Glass with Guard and Nitrile Seal. Max Pressure is 44 PSI
Saddle Mount Hydraulic Tanks
Part No. Description
FTA-HT-025R 25 Gallon Alum Saddle Mnt Hydraulic Tank, w/ Filler Breather Cap, Level/Temp Gauge, 2-Ports Includes FTA-BCA-32 LENZ Filler Breather Cap / 40 Micron Nylon Strainer and FTA-SG-46 LENZ Sight Level Gauge w Temp Control.
FTA-HT-035R 35 Gallon Alum Saddle Mnt Hydraulic Tank, w/ Filler Breather Cap, Level/Temp Gauge, 2-Ports Includes FTA-BCA-32 LENZ Filler Breather Cap / 40 Micron Nylon Strainer and FTA-SG-46 LENZ Sight Level Gauge w Temp Control.
FTA-HT-050R 50 Gallon Alum Saddle Mnt Hydraulic Tank w/ Filler Breather Cap, Level/Temp Gauge, 2-Ports Includes FTA-BCA-32 LENZ Filler Breather Cap / 40 Micron Nylon Strainer and FTA-SG-46 LENZ Sight Level Gauge w Temp Control.
Up-Right Hydraulic Tanks
Part No. Description
FTA-HT-633 35 Gallon Alum Up-right Hydraulic Tank w/ Hardware, Breather Cap, Level/Temp Gauge, 2-Ports Includes FTA-BCA-32 LENZ Filler Breather Cap / 40 Micron Nylon Strainer and FTA-SG-46 LENZ Sight Level Gauge w Temp Control.
FTA-HT-632 50 Gallon Alum Up-rightHydraulic Tank w/ Hardware, Breather Cap, Level/Temp Gauge, 2-Ports Includes FTA-BCA-32 LENZ Filler Breather Cap / 40 Micron Nylon Strainer and FTA-SG-46 LENZ Sight Level Gauge w Temp Control.

Parts & Accessories - Parts & Accessories

T-Handle Kit
Part No. Description WxDxH (in) Wt. (lbs)
FTSS001 Replacement T-Handle, stainless steel w/ foam gasket & rivets - randomly keyed 4.75 x 2.6875 x 4.9375 1.5
PTO Control Bracket, SS
Part No. Description WxDxH (in) Wt. (lbs)
G408 PTO Control Bracket for Chelsea, floor mount, stainless steel 6 x 7.5 x 5.25 1.1
KW Air Spring Bracket
Part No. Description WxDxH (in) Wt. (lbs)
K048-449S Kenworth Air Spring Bracket, steel, powder coated, heavy duty 8 x 8 x 3 6
Slide Bar Latch Kit
Part No. Description WxDxH (in) Wt. (lbs)
PD015 Slide bar Latch, stainless steel slide bar w/ aluminum tab & mounting hardware 6.75 x 1.281 x 3.275 1.2

Parts & Accessories - TANK COMPONENTS FTA

Premium Fuel Tank components with un-matched reliability and performance.

Contact factory for custom options or bulk pricing for manufacturing.

Fuel Tank Necks
Part No. Description
FTA-N-04 Neck Steel 2.0"-11.5 NPSH x 2.74" Length
FTA-N-20 Neck Alum 3.00"-8 NPSL x 3.575" Length for Volvo, Mack, International
FTA-N-49 Cam Neck Cast Alum 1/4 Turn 2.97±.01 Long for Freightliner
FTA-N-72 Neck Alum 2.5"-8 UN 2A x 3.00" Length
FTA-N-914 Neck Alum 4.00"-8 NPSL x 4.00" Length
FTA-N-92 Neck Alum 2.5"-8 UN Triple lead x 2.30" Length for Freightliner M2
FTA-N-988 Neck Steel 4.00"-8 NPT x 4.00" Length
FTA-N4-73 Neck Alum 2.0"-11.5 NPSH x 4.00"Length
FTA-N6-73 Neck Alum 2.0"-11.5 NPSH x 6.00" Length
Fuel Tank Repair Bands
Part No. Description
FTA-30TRB-4 Alum Tank Skin repair band 4" wide, up to 30" Tank Diameter
FTA-30TRB-6 Alum Tank Skin repair band 6" wide, up to 30" Tank Diameter
FTA-30TRB-8 Alum Tank Skin repair band 6" wide, up to 30" Tank Diameter
Diesel Fuel Tank Adapters/Flanges
Part No. Description
FTA-A-29-03 Adapter Alum Bottom Drain
FTA-A-10 Adapter Alum for Ø24.0 Tank W/ Ø4.66 Flat & no Holes
FTA-A-31 Adapter Alum Radiused 12.31 W/ Sender Mount & 2 EA 1/2 NPSF & 1 EA 1/4 NPSF
FTA-A-33 Adapter Alum Radius 12.31 W/ Sender Mount & 2 Ea.1/2" NPSF Thread & 1 Ea. 1/4" NPSF Thread
FTA-A-34 Adapter Steel Radius 12.31 W/ Sender Mount & 2 Ea. 1/2" NPSF Thread & 1 Ea. 1/4" NPSF Thread
FTA-A-53R Cluster Plate Assy. W/Tube Steel R.H. 2 Ea. 1/2" NPT Thread Ports Also includes 3/8" NPT Thread, Tube Port Immerse in Rust Inhibitor
Aluminum Weld Flanges
Part No. Description
FTA-ALB-125R 1/8"- Full Round OD 0.160 Alum Weld Flange - 0.160 Thickness
FTA-ALB-1000R 1"- Full Round OD 0.160 Alum Weld Flange - 0.160 Thickness Bulk pricing available on orders of 100 plus.
FTA-ALB-1250C 1.25"- Flats on OD-Curved 0.160 Alum Weld Flange - 0.160 Thickness Also available on Flat Weld Flange (use part # FTA-C-1250F)
FTA-ALB-1500C 1.5"- Flats on OD-Curved 0.160 Alum Weld Flange - 0.160 Thickness Also available on Flat Weld Flange (use part # FTA-C-1500F)
FTA-ALB-2000F 2"- Flats on OD-Flat 0.190 Alum Weld Flange - 0.190 Thickness
FTA-ALB-250R 1/4"- Full Round OD 0.160 Alum Weld Flange - 0.160 Thickness
FTA-ALB-375R 3/8"- Full Round OD 0.160 Alum Weld Flange - 0.160 Thickness Flats also available (use part # FTA-ALB-375F)
FTA-ALB-500R 1/2"- Full Round OD 0.160 Alum Weld Flange - 0.160 Thickness Flats also available (use part # FTA-ALB-500F)
FTA-ALB-750R 3/4"- Full Round OD 0.160 Alum Weld Flange - 0.160 Thickness
FTA-ALB-RING-C C Sending Unit Gage Ring Curved Flat option aslo available (use part # FTA-ALB-RING-F)
Drain Check Valves
Part No. Description
FTA-DP-55 1/2" Brass Drain Check Valve W/Brass Plug
FTA-DP-78 3/8" Brass Drain Check Valve W/Brass Plug
Stand Pipes / Draw Tubes
Part No. Description
FTA-DT-11.89 Stand Pipe Brass 11.89 Long W/ Fitting .500-14 NPTF Ext W/ Vibra-seal & .375-18 NPTF Int
FTA-DT-14.49 Stand Pipe Brass 14.49 Long W/ Fitting .500-14 NPTF Ext W/ Vibra-seal & .375-18 NPTF Int
FTA-DT-17.80 Stand Pipe Brass 17.80 Long W/ Fitting .500-14 NPTF Ext W/ Vibraseal & .375-18 NPTF Int : NOTE:
FTA-DT-20.95 Stand Pipe Brass 20.95 Long W/ Fitting .500-14 NPTF Ext W/ Vibra-seal & .375-18 NPTF Int
FTA-DT-28.03 Stand Pipe Brass 28.03 Long W/ Fitting .500-14 NPTF Ext W/ Vibra-seal & .375-18 NPTF Int
FTA-DT-38.50 Stand Pipe Brass 38.50 Long W/ Fitting .500-14 NPTF Ext W/ Vibra-seal & .375-18 NPTF Int
Stand Pipes / Draw Tubes
Part No. Description
FTA-DT-22.92 Stand Pipe Brass 22.92 Long W/ Fitting .500-14 NPTF Ext W/ Vibra-seal & .375-18 NPTF Int
Fuel Tank Fill Necks w/ Flanges
Part No. Description
FTA-FN-94 Neck & Pocket Alum 3.0"- 8 NPSL Thread, W/13.69 R, No Lettering. International, Volvo, Mack Fuel Tank
FTA-NF-10 Cam Neck & Pocket Assy Alum No Lettering. Freightliner Fuel Tank
FTA-NF-16 Tear Drop Assy Alum Ø 26 Dia W/ 2.88" - 8 UNNS Fill Neck Sender mount Vent port & Heater Port No Lettering. Volvo Low Sulfur Fuel Tank
FTA-NF-19 Neck & Pocket Alum 3.0"- 8 NPSL Thread, with Flange. International, Volvo, Mack Fuel Tank
FTA-NF-52 Tear Drop Assy Alum Ø 26 Dia W/ 3" - 8 NPSL Fill Neck Sender Mount 1/4 NPTF Heater & 1/2 NPTF Vent Ports No Lettering. Volvo non-Low Sulfur Fuel Tank
FTA-NF-55 Tear Drop Assy Alum Ø 22 Dia W/ 2.88" - 8 UNNS Fill Neck, Sender Mount & Vent Port & Heater Port No Lettering. Volvo Low Sulfur Fuel Tank
FTA-NF-857 Neck & Pocket Alum Ø26.0 Tank Radius, No Lettering. Peterbilt Fuel Tank
FTA-NP-28-24.5 Neck & Pocket Alum 3.5"- 5.5 NS Thread, Ø24.5 Tank Radius, No Lettering. Kenworth Fuel Tank
J1114 Style Fuel Fill Necks
Part No. Description
FTA-N-TWI2 Fill Neck Steel, J1114 thin wall 2.69" length
FTA-C-L Steel Fill Neck Cap for 2.593" OD, Vented, W/ Lug,
FTA-INS Steel Fuel Fill Neck Cap Insert J1114 Diesel Engine Open Bottom/No Flapper
FTA-N-B1 Fill Neck Steel 2.281" OD x 1.219" Long
FTA-N-B2 Fill Neck Steel 2.281" OD x 2.688" Long
FTA-N-L Fill Neck Steel 2.593" OD x 1.188" Long W/ Lug,
FTA-N-TI2 Fill Neck Steel, J1114 thick wall 2.69" length
FTA-N-TI4 Fill Neck Steel, J1114 thick wall 4.50" length
FTA-N-TI6 Fill Neck Steel, J1114 thick wall 6.50" length
FTA-N-TWI4 Fill Neck Steel, J1114 thin wall 4.50" length
FTA-N-TWI6 Fill Neck Steel, J1114 thin wall 6.50" length
HD Radiator Neck
Part No. Description
FTA-RN-2 Alum 2"NPT Radiator Fill Neck (machined)
Steel Weld Flanges
Part No. Description
FTA-STB-125S 1/8"- 1.125 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-1000C T 1"- Container 0.134 Steel Weld Flange - 0.134 Thickness Bulk pricing available on orders of 100 plus.
FTA-STB-1250C 1.25"- Curved 0.118 Steel Weld Flange - 0.118 Thickness Also available on Flat Weld Flange (use part # FTA-STB-1250F)
FTA-STB-1250H DF 1.25"- HD-Flat 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-125F 1/8"- 1.750 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-1500C 1.5"- Curved 0.118 Steel Weld Flange - 0.118 Thickness Flat option aslo available (use part # FTA-STB-1500F)
FTA-STB-2000C 2"- Curved 0.130 Steel Weld Flange - 0.130 Thickness Flat option aslo available (use part # FTA-STB-2000F)
FTA-STB-2000HDC DC 2"- HD-Curved 0.156 Steel Weld Flange - 0.156 Thickness Flat option aslo available (use part # FTA-STB-2000HDF)
FTA-STB-250F 1/4"- 1.750 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-250S 1/4"- 1.125 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-375F 3/8"- 1.750 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-375S 3/8"- 1.125 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-500F 1/2"- 1.750 OD 0.134 Steel Weld Flange - 0.134 Thickness
FTA-STB-750C 3/4"- Curved 0.134 Steel Weld Flange - 0.134 Thickness Flat option aslo available (use part # FTA-STB-750F)
FTA-STB-RING-C C Steel Gauge Rings Curved Flat option aslo available (use part # FTA-STB-RING-F)
Fuel Tank End Caps
Part No. Description
FTA-TE-26PB Tank End Alum .125 x 26.00 Ø 5052-H32 Including Peterbilt tanks.
FTA-TB-26N Tank Baffle Alum w/o Holes .125 x 26.00 Ø 5052-H32 Western Star split tank application.
FTA-TE-24.5KW Tank End Alum .125 x 24.5 Ø 5052-H32 Including Kenworth tanks.
FTA-TE-24H Tank End Alum w/ Holes .125 x 24 Ø 5052-H32 Flat Profile Hydraulic tanks.
FTA-TE-24HN Tank End Alum w/o Holes .125 x 24 Ø 5052-H32 Flat Profile Hydraulic tanks.
FTA-TE-WS868-01 Tank End Alum w/ Holes .125 x 26.00 Ø 5052-H32 Including Western Star tanks.
FTA-TE-WS868-02 Tank End Alum w/o Holes .125 x 26.00 Ø 5052-H32 Including Western Star tanks.
3/4" Vent Assemblies
Part No. Description
FTA-V-19 Vent Assembly Brass 0.75-14 NPTF short w/ Single Barb for 0.50 ID Hose 4.5" Length, 4-hole
FTA-V-05 Vent assy Brass 0.75-14 NPTF short w/ single barb for 0.50 ID hose 4.5" Length, 2-hole
3/8" Vent Assemblies
Part No. Description
FTA-V-22 Vent Assembly Brass 0.375-18 NPTF Single Barb for 0.312" ID Hose 2 -Hole Cage
1/2" Vent Assemblies
Part No. Description
FTA-V-37 Vent Assembly Brass 0.50-14 NPTF w/ sealant & Single Barb for 0.312" ID Hose 2 -Hole Cage
FTA-V-45 Freightliner vent Assembly Brass 1/2" threads 0.50-14 NPTF Single Barb for 0.312" ID Hose 2 -Hole Cage Freightliner Application TM-90-04926
FTA-V-50-01 Peterbilt vent Assembly Full-function 1/2" threads Double Barb for 0.25" ID Hose 230F thermal relief
FTA-V-50-02 Peterbilt vent assy full-function double barb for 0.25" ID hose 230F thermal relief w/ Vibra Seal on Threads
FTA-V-50-03 Volvo, Kenworth vent Assembly Full-function 1/2 threads Single Barb for 5/16" ID Hose 230F thermal relief
FTA-V-50-04 Volvo, Kenworth vent Assembly Full-function 1/2 threads Single Barb for 5/16" ID hose 230F thermal relief w/ Vibra Seal on Threads
FTA-V-956 Vent Assembly Brass 0.50-14 NPTF Double Barb for 0.25" ID Hose 2 -Hole Cage
1/4" Vent Assemblies
Part No. Description
FTA-V-40 Vent Assembly Brass 1/2" threads 0.25-18 NPTF Double Barb for 0.25" ID Hose
FTA-V-48 Vent Assembly Brass 1/4" Threads 0.25-18 NPTF w/o Barb
FTA-V-56 Vent Assembly Brass 0.25-18 NPTF Single Barb for 0.312" ID Hose
FTA-V-99 Vent Assembly Brass 0.25-18 NPTF Double Barb for 0.25" ID Hose 4 -Hole Cage
FTA-V-99-01 Vent Assembly Brass 0.25-18 NPTF w/ Sealant Double Barb for 0.25" ID Hose 4 -Hole Cage
Thermal Relief Plug Assembly
Part No. Description
FTA-V-59 Thermal relief plug Assembly 1.25-11.5 NPTF @ 190F

Parts & Accessories - TANK MOUNTING FTA

Tank Mounting Options to fit most makes and models of trucks and tank sizes.

Steel and Aluminum Strap Options with Premium Rubber Backing in multiple widths.

Kenworth Tank Bracket
Part No. Description
FTA-TB-KW-24.5 Kenworth Fuel Tank Bracket, 8 Guage Painted Steel, Fitst 24.5" Tanks Straps Sold Seperately
Hydraulic Tank Strap & Bracket
Part No. Description
FTA-TS-24H 2" Stainless Steel Hydraulic Tank Strap for 24" Cylindrical Tanks (T-Bolts both ends) T-Bolt to T-Bolt Ends: 64.25", Strap to Strap Ends: 57.75"
FTA-TB24 Frame Mounted Hydraulic Tank J-Bracket, Powder Coated Straps Sold Seperately
Freightliner Tank Straps
Part No. Description
FTA-TS-FM2S 2" Fuel Tank Strap WITH STEP for Freigtliner M2, FL70/80, Painted Steel T-Bolt to Strap End: 39", Strap to Strap Ends: 37"
FTA-TS-FM2P 2" Fuel Tank Strap WITHOUT STEP for Freigtliner M2, FL70/80, Painted Steel T-Bolt to Strap End: 39", Strap to Strap Ends: 37"
FTA-TS-FM2SS 2" Fuel Tank Strap WITHOUT STEP for Freigtliner M2, FL70/80, Stainless Steel T-Bolt to Strap End: 39", Strap to Strap Ends: 37"
FTA-TS-FM2SSS 2" Fuel Tank Strap WITH STEP for Freigtliner M2, FL70/80, Stainless Steel T-Bolt to Strap End: 39", Strap to Strap Ends: 37"
International Tank Straps
Part No. Description
FTA-TS-IN16D 2" Stainless Fuel Tank Strap WITHOUT STEP for International 4000 Series 16"D-Round Tanks T-Bolt to Strap End: 42.5", Strap to Strap Ends: 38.5"
FTA-TS-IN19D 2" Stainless Fuel Tank Strap WITHOUT STEP for International 4000 Series 19"D-Round Tanks T-Bolt to Strap End: 44.5", Strap to Strap Ends: 40.5"
FTA-TS-IN26 2" Stainless Steel Fuel Tank Strap WITHOUT STEP for International 26" Tanks T-Bolt to Strap End: 69", Strap to Strap Ends: 65"
FTA-TS-INP16D 2" Painted Steel Fuel Tank Strap WITH STEP for International 4000 Series 16"D-Round Tanks T-Bolt to Strap End: 42.5", Strap to Strap Ends: 38.5"
FTA-TS-INP26 2" Painted Steel Fuel Tank Strap WITHOUT STEP for International 26" Tanks T-Bolt to Strap End: 68", Strap to Strap Ends: 64.25"
FTA-TS-INPR 2" Painted Steel Fuel Tank Strap WITHOUT STEP for International 4700/4900 Rectangular Tanks T-Bolt to Strap End: 44", Strap to Strap Ends: 41"
FTA-TS-INPS26 2" Painted Steel Fuel Tank Strap WITH STEP for International 26" Tanks T-Bolt to Strap End: 68", Strap to Strap Ends: 64.25"
FTA-TS-INS16D 2" Stainless Fuel Tank Strap WITH STEP for International 4000 Series 16"D-Round Tanks T-Bolt to Strap End: 42.5", Strap to Strap Ends: 38.5"
FTA-TS-INS19D 2" Stainless Fuel Tank Strap WITH STEP for International 4000 Series 19"D-Round Tanks T-Bolt to Strap End: 44.5", Strap to Strap Ends: 40.5"
FTA-TS-INS26 2" Stainless Steel Fuel Tank Strap WITH STEP for International 26" Tanks T-Bolt to Strap End: 69", Strap to Strap Ends: 65"
Kenworth Tank Straps
Part No. Description
FTA-TS-KS 2" Fuel Tank Strap, Stainless Steel WITH STEP, Fits Kenworths 24.5" Tanks T-Bolt to Strap End: 45", Strap to Strap Ends: 40.5"
FTA-TS-K 2" Fuel Tank Strap, Stainless Steel WITHOUT STEP, Fits Kenworths 24.5" Tanks T-Bolt to Strap End: 45", Strap to Strap Ends: 40.5"
FTA-TS-K19 2" Fuel Tank Strap, Stainless Steel WITHOUT STEP, Fits Kenworths 19" Tanks T-Bolt to Strap End: 34", Strap to Strap Ends: 30"
FTA-TS-KFD 2" Fuel Tank Strap, Painted Steel for Driver's Side Fairing Application, Fits Kenworths 24.5" Tanks T-Bolt to Strap End: 46", Strap to Strap Ends: 41.5"
FTA-TS-KFP 2" Fuel Tank Strap, Painted Steel for Passenger Side Fairing Application, Fits Kenworths 24.5" Tanks T-Bolt to Strap End: 46", Strap to Strap Ends: 41.5"
Peterbilt Tank Straps
Part No. Description
FTA-TS-P26S 2" Fuel Tank Strap, Stainless Steel, Fits Peterbilt 26" Tanks T-Bolt to Strap End: 69", Strap to Strap Ends: 63"
FTA-TS-P23AP 2" Fuel Tank Strap, Polished Aluminum, Fits Peterbilt 23" Tanks T-Bolt to Strap End: 60", Strap to Strap Ends: 54.5"
FTA-TS-P26AP 2" Fuel Tank Strap, Polished Aluminum, Fits Peterbilt 26" Tanks T-Bolt to Strap End: 69", Strap to Strap Ends: 63"
Reefer Tank Straps
Part No. Description
FTA-TS-R19 2" Fuel Tank Strap, Stainless Steel, Fits Reefer Trailer 19" Tanks (T Bolts on both ends) T-Bolt to T-Bolt Ends: 59.5", Strap to Strap Ends: 50.5"
FTA-TS-R22 2" Fuel Tank Strap, Stainless Steel, Fits Reefer Trailer 22" Tanks (T Bolts on both ends) T-Bolt to T-Bolt Ends: 62.5" , Strap to Strap Ends: 53.5"
2" Tank Strap Backing
Part No. Description
FTA-TSB-2 2" Tank Strap Backing (Standard) Available in 4', 5', 10', 20' and 50' Lengths
FTA-TSB-2HD 2" Tank Strap Backing (Heavy Duty, Non-Slip, Ribbed) Available in 4', 5', 10', 20' and 50' Lengths
FTA-TSB-2HD-33 2" Rubber Tank Strap Backing for Kenworth 24.5" Tanks., 33" Long
Part No. Description
FTA-TSB-3HD-37 3" Rubber Tank Strap Backing for Kenworth, 37" Long
3" Tank Strap Backing
Part No. Description
FTA-TSB-3 3" Tank Strap Backing (Standard) Available in 4', 5', 10', 20' and 50' Lengths
FTA-TSB-3HD 3" Tank Strap Backing (Heavy Duty, Non-Slip, Ribbed) Available in 4', 5', 10', 20' and 50' Lengths
3.5" Tank Strap Backing
Part No. Description
FTA-TSB-3.5 3.5" Tank Strap Backing (Standard) Available in 4', 5', 10', 20' and 50' Lengths
FTA-TSB-3.5HD 3.5" Tank Strap Backing (Heavy Duty, Non-Slip, Ribbed) Available in 4', 5', 10', 20' and 50' Lengths
4" Tank Strap Backing
Part No. Description
FTA-TSB-4 4" Tank Strap Backing (Standard) Available in 4', 5', 10', 20' and 50' Lengths
FTA-TSB-4HD 4" Tank Strap Backing (Heavy Duty, Non-Slip, Ribbed) Available in 4', 5', 10', 20' and 50' Lengths

Portable Welding - Accessories

Propane Tank Holder
Part No. Description WxDxH (in) Wt. (lbs)
LPG20 Propane tank holder - fits 20 & 30lb tanks, includes backing plate 13 x 13 x 18 10.5
Oxygen Bottle Racks
Part No. Description WxDxH (in) Wt. (lbs)
O21H Oxygen cylinder storage system, single horizontal bottle with clamp 11 x 50 x 11.25 48
O22H Oxygen cylinder storage system, dual horizontal bottles side by side "T" clamp 20 x 50 x 10.5 75
O22V Oxygen cylinder storage system, dual horizontal bottles stacked with "H" & "U" clamp 10.625 x 50 x 20.625 78
Acetylene Bottle Racks
Part No. Description WxDxH (in) Wt. (lbs)
ACET-1V Acetylene bottle rack with bolt-on clamp 12.25 x 8.813 x 20.688 0
ACET-1V-STRAP Acetylene bottle rack with ratchet strap 10.5 x 4 x 20.5 0
Anti-theft Covers for AlumaReel
Part No. Description WxDxH (in) Wt. (lbs)
ATC2 Anti-theft Covers for AlumaReel, pair 14 x 14 x 10 10
ATC2SR Anti-theft Covers for Shell-Ryn, pair 14 x 14 x 10 10.8

Step & Access Products - Frame Covers

Frame-width Platforms formed from 3/16" Aluminum Checker Plate Sheet with crossed channel supports and included Z-clips.

Additional spacers, reinforcements and custom dimensions are available on request.

Checker Plate Aluminum Frame Covers
Part No. Description WxDxH (in) Wt. (lbs)
FC36 Frame Cover, 36"L x 34.25"W, 3/16" checker aluminum 34.25 x 36 x 1 28
FC48 Frame Cover, 48"L x 34.25"W, 3/16" checker aluminum 34.25 x 48 x 1 37
FC60 Frame Cover, 60"L x 34.25"W, 3/16" checker aluminum 34.25 x 60 x 1 45

Step & Access Products - Frame Steps

HD Aluminum Channel Grip Steps with flanged aluminum Side Mounts

Options include choice of: smooth or checker plate sides and round or diamond patterned grip steps.

Frame Steps
Part No. Description WxDxH (in) Wt. (lbs)
FS12RND Frame Step, 12" Wide, two Round Grip steps, smooth finish 12 x 10.5 x 23 8
FS08DIA Frame Step, 8" Wide, two Diamond Grip steps , smooth finish 8 x 10.5 x 23 7
FS08RND Frame Step, 8" Wide, two Round Grip steps, smooth finish 8 x 10.5 x 23 7
FS12DIA Frame Step, 12" Wide, two Diamond Grip steps, smooth finish 12 x 10.5 x 23 8
FS14DIA Frame Step, 14" Wide, two Diamond Grip steps, smooth finish 14 x 10.5 x 23 8
FS14RND Frame Step, 14" Wide, two Round Grip steps, smooth finish 14 x 10.5 x 23 8

Step & Access Products - Miscellaneous

Misc Peterbilt Accessories
Part No. Description WxDxH (in) Wt. (lbs)
11-3987-745 Step Grip Edge, Peterbilt style, 29.375”L (745mm), aluminum 30 x 0.5 x 2 1.5

Step & Access Products - Pedestal Steps

Adjustable Bolt-On Grip Strut Steps with Single-Post Mount.

Options include choice of: smooth or checker plate sides and round or diamond patterned grip steps.

Adjustable Pedestal Steps
Part No. Description WxDxH (in) Wt. (lbs)
PS08RND Pedestal Step, 8" Wide, two Round Grip steps on angled tube 8 x 19.75 x 21 9
PS06DIA Pedestal Step, 6" Wide, two Diamond Grip steps on angled tube 6 x 19.75 x 21 8
PS06RND Pedestal Step, 6" Wide, two Round Grip steps on angled tube 6 x 19.75 x 21 8
PS08DIA Pedestal Step, 8" Wide, two Diamond Grip steps on angled tube 8 x 19.75 x 21 9

Step & Access Products - Walking Decks

Frame-width Platforms formed from Grip Strut Step Lengths stitched together w/ capped ends.

Options include choice of: smooth or checker plate sides and round or diamond patterned grip steps.

Diamond Grip Strut Walking Decks
Part No. Description WxDxH (in) Wt. (lbs)
WD24DIA Walking Deck, 24"L x 33"W, Diamond Grip channel 33 x 24 x 2 22
WD36DIA Walking Deck, 36"L x 33"W, Diamond Grip channel 33 x 36 x 2 22
WD40DIA Walking Deck, 36"L x 33"W, Diamond Grip channel 33 x 40 x 2 22
Round Hole Grip Strut Walking Decks
Part No. Description WxDxH (in) Wt. (lbs)
WD30RND Walking Deck, 30"L x 33"W, Round Grip channel 33 x 30 x 2 22
WD36RND Walking Deck, 36"L x 33"W, Round Grip channel 33 x 36 x 2 22
WD40RND Walking Deck, 40"L x 33"W, Round Grip channel 33 x 40 x 2 30
WD48RND Walking Deck, 48"L x 33"W, Round Grip channel 33 x 48 x 2 42

Tire Chain Hangers - Combo with Fender Bracket

Combo brackets are three-hook tire chain hangers with mounting capability for mud flaps or fenders that fit specific applications, models and suspension systems.

Options exist that fit Low-Air Leaf, Hendrickson, Airliner, Primaax, Newway systems and most PACAAR, Daimler, International, Mack and Volvo frames.

Tire Chain Hangers/Fender Mounts for PRIMAAX
Part No. Description WxDxH (in) Wt. (lbs)
KWPX321L Kenworth PRIMAAX Combo Tire Chain Hanger / Fender Bracket w/ checker plate Lid - LEFT 31 x 5.75 x 9 35
KWPX321R Kenworth PRIMAAX Combo Tire Chain Hanger / Fender Bracket w/ checker plate Lid - RIGHT 31 x 5.75 x 9 35
KWPX321WTL Kenworth PRIMAAX Wide Track Combo Tire Chain Hanger / Fender Bracket w/ checker plate Lid - LEFT 34 x 5.75 x 9 40
KWPX321WTR Kenworth PRIMAAX Wide Track Combo Tire Chain Hanger / Fender Bracket w/ checker plate Lid - RIGHT 34 x 5.75 x 9 40
Tire Chain Hangers/Fender Mounts for Peterbilt Low Air Leaf
Part No. Description WxDxH (in) Wt. (lbs)
PBLA321L Peterbilt Low Air Leaf Combo Tire Chain Hanger / Fender Bracket w/ checker plate Lid - LEFT 31 x 7.5 x 7 35
PBLA321R Peterbilt Low Air Leaf Combo Tire Chain Hanger / Fender Bracket w/ checker plate Lid - RIGHT 31 x 7.5 x 7 35
TCH3-AL Chain Hangers/ Fender Mounts for Airliner
Part No. Description WxDxH (in) Wt. (lbs)
TCH3-AL-L-G Tire Chain Hanger Fender Bracket Airliner Left Galvanized 30 x 10.5 x 8 31
TCH3-AL-L Tire Chain Hanger Fender Bracket Airliner Left Powder Coated 0 x 0 x 0 0
TCH3-AL-R Tire Chain Hanger Fender Bracket Airliner Right Powder Coated 0 x 0 x 0 0
TCH3-AL-R-G Tire Chain Hanger Fender Bracket Airliner Right Galvanized 30 x 10.5 x 8 31
TCH3-AL-WT-L-G TCH3 Airliner Wide Track Left Galvanized 33 x 10.5 x 8 31
TCH3-AL-WT-R-G TCH3 Airliner Wide Track Right Galvanized 33 x 10.5 x 8 31
HD Formed Narrow Base Tire Chain Hangers
Part No. Description WxDxH (in) Wt. (lbs)
TCH3-NB-L TCH3 Narrow Base LEFT 30.5 x 8 x 8 32
TCH3-NB-L-G TCH3 Narrow Base Left Galvanized 30.5 x 8 x 8 32
TCH3-NB-R TCH3 Narrow Base RIGHT 30.5 x 8 x 8 32
TCH3-NB-R-G TCH3 Narrow Base Right Galvanized 30.5 x 8 x 8 32
TCH3-NB-WT-L TCH3 Narrow Base Wide Track Left 33 x 8 x 8 33
TCH3-NB-WT-L-G TCH3 Narrow Base Wide Track Left Galvanized 33 x 8 x 8 33
TCH3-NB-WT-R TCH3 Narrow Base Wide Track Right 33 x 8 x 8 33
TCH3-NB-WT-R-G TCH3 Narrow Base Wide Track Right Galvanized 33 x 8 x 8 33
TCH3-AL Chain Hangers/ Fender Mounts for Neway ADZ
Part No. Description WxDxH (in) Wt. (lbs)
TCH3-NW-L TCH3 Neway ADZ Left 30 x 6.375 x 6.375 28
TCH3-NW-L-G TCH3 Neway ADZ Left Galvanized 30 x 6.375 x 6.375 28
TCH3-NW-R TCH3 Neway ADZ Right 30 x 6.375 x 6.375 28
TCH3-NW-R-G TCH3 Neway ADZ Right Galvanized 30 x 6.375 x 6.375 28
TCH3-NW-WT-L-G TCH3 Neway ADZ Wide Track Left Galvanized 0 x 0 x 0 0
TCH3-NW-WT-R-G TCH3 Neway ADZ Wide Track Right Galvanized 0 x 0 x 0 0
Rear Frame Mounted Tire Chain Hangers
Part No. Description WxDxH (in) Wt. (lbs)
TCH3-RF-L TCH3 Rear of Frame Left 30.5 x 8 x 8 32
TCH3-RF-L-G TCH3 Rear of Frame Left - Galvanized 8 x 30.5 x 8 0
TCH3-RF-R TCH3 Rear of Frame Right 30.5 x 8 x 8 32
TCH3-RF-R-G TCH3 Rear of Frame Right - Galvanized 8 x 30.5 x 8 0

Tire Chain Hangers - Pull-Out

Heavy Duty powder coated steel chain hangers that pull-out for easy access featuring 6 hooks and lockable lids.

Low-Friction Pull-Out Tire Chain Hanger
Part No. Description WxDxH (in) Wt. (lbs)
TCH6PO Low-friction Pull-Out Tire Chain Hanger 8 x 30 x 10 0
TCH6PO-SS Low-friction Pull-Out Tire Chain Hanger - Stainless Lid 8 x 30 x 10 0

Tire Chain Hangers - Straight

Heavy Duty steel chain hangers with 5-6 hooks and lockable checker plate aluminum lids.

Fixed Tire Chain Hangers w/ Lids
Part No. Description WxDxH (in) Wt. (lbs)
TCH326 REAR 5 Hook Tire Chain Hanger, galv. w/ lockable lid, 34" long (end of frame mount) 33.625 x 5.8125 x 6.5 32
F324 HEAVY DUTY 6 Hook Tire Chain Hanger w/ lockable lid 30.3125 x 8.25 x 10.25 34

Trailer - Dunnage Trays

Open dunnage storage option from lightweight aluminum with self-draining design.

Adjustable to fit most platform trailers both flat & drop deck

Dunnage Tray Kits w/ Mount Kit
Part No. Description WxDxH (in) Wt. (lbs)
DT1002210-82 Dunnage Tray Kit 100W22D10H w/ T82 mount kit 99.438 x 23.563 x 21.25 85
DT1202210-82 Dunnage Tray Kit 120W22D10H w/ T82 mount kit 119.438 x 23.563 x 21.25 95

Trailer - Accessories

Dolly Pad Holders
Part No. Description WxDxH (in) Wt. (lbs)
DPH161803 Dolly Pad Holder, 16"W x 18"D x 3"H - holds two plastic 15"x17"x1" dolly pads, 3/16" aluminum 16 x 18 x 3 8
DPH232405.5 Dolly Pad Holder, 23"W x 24"D x 5.5"H - holds wood style dolly pads, 3/16" aluminum 23 x 24 x 5.5 18
Load Leveller Parts
Part No. Description WxDxH (in) Wt. (lbs)
B200-01 Replacement Pinning Stake, Sliding / Floating style for Load Bunk, aluminum 3.5 x 2 x 11.1875 2
B200-02 Replacement Pinning Stake, Solid / Fixed style for Load Bunk, bolt-on w/ shim, aluminum 5.25 x 1.5 x 9.75 2
B200-10 Replacement Chain Hook for Load Bunk, steel, galvanized - includes backing plate 4 x 2 x 4 1
B200-20 Replacement Stake Pocket for Load Bunk, bolt-on, aluminum 5.75 x 2.25 x 4 1

Trailer - Dunnage Boxes

Dunnage boxes come standard with Locking T-Handle latches and feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of finish, Whale Tail Latches, Alternative Hinge Location (Standard orientation is mirrored hinge placement)

Dunnage Boxes
Part No. Description WxDxH (in) Wt. (lbs)
DB1810024 Dunnage Box 18Wx100Dx18H, full doors both ends, T-handles - smooth finish 18 x 100 x 24 125
DB1810020 Dunnage Box 18Wx100Dx18H, full doors both ends, T-handles - smooth finish 18 x 100 x 20 111
DB186418 Dunnage Box 18Wx64Dx18H, full doors both ends, T-handles - smooth finish 18 x 64 x 18 73
DB2410020SL Dunnage Box 24Wx100Dx20H, full doors both ends, slide latches - smooth finish 24 x 100 x 20 129
DB2410020SL-CPD Dunnage Box 24Wx100Dx20H, full doors both ends, slide latches - smooth body checker doors 24 x 100 x 20 130
DB249636WT-CP Dunnage Box 24Wx96Dx36H, full doors both ends, Whale Tail latches- checker finish 24 x 96 x 36 192

Trailer - Load Levelers

Lightweight Aluminum Load Levellers (aka Load Bunks) are made to order. Aluminum construction resists corrosion, while replaceable pressure-treated wood extends the service life.

Galvanized bolt on steel tie down hooks ensure load bunk stability. Available with solid or floating pinning stakes.

21-23" Tall Load Levellers
Part No. Description WxDxH (in) Wt. (lbs)
B221-28-02 Load Leveller, 21"Hx97.25"W, fixed pinning stakes w/ shims 97.25 x 6 x 21 85
B221-26-02 Load Leveller, 21" Hx97" W, fixed pinning stakes w/ shims 97 x 6 x 21 85
B221-29-01 Load Leveller, 21"Hx97.375"W, sliding pinning stakes 97.375 x 6 x 21 85
B222-29-01 Load Leveller, 22.5"Hx96.75"W, sliding pinning stakes 97.375 x 6 x 22 85
24 -28" Tall Load Levellers
Part No. Description WxDxH (in) Wt. (lbs)
B224-31-01 Load Leveller, 24"Hx97.625"W, sliding pinning stakes 97.625 x 6 x 24 85
B226-26-02 Load Leveller, 26"Hx97"W, fixed pinning stakes w/ shims 97 x 6 x 26 85
16-19" Tall Load Levellers
Part No. Description WxDxH (in) Wt. (lbs)
B216-30-02 Load Leveller, 16"Hx97.5"W, fixed pinning stakes w/ shims 97.5 x 6 x 16 85
B218-30-01 Load Leveller, 18"Hx97.5"W, sliding pinning stakes 97.5 x 6 x 18 85
B218.25-30-01 Load Leveller, 18.25"Hx97.5"W, sliding pinning stakes 97.5 x 6 x 18.25 85
B219-28-02 Load Leveller, 19"Hx97.25"W, fixed pinning stakes w/ shims 97.25 x 6 x 19 85
B219-29-01 Load Leveller, 19"Hx97.5"W, sliding pinning stakes 97.375 x 6 x 19 85
B219-30-01 Load Leveller, 19"Hx97.5"W, sliding pinning stakes 97.5 x 6 x 19 85
20" Tall Load Levellers
Part No. Description WxDxH (in) Wt. (lbs)
B220-26-01 Load Leveller, 20"Hx97"W, sliding pinning stakes 97 x 6 x 20 85
B220-28-02 Load Leveller, 21"Hx97.25"W, fixed pinning stakes w/ shims 97.25 x 6 x 20 85
B220-30-01 Load Leveller, 20"Hx97.5"W, sliding pinning stakes 97.5 x 6 x 20 85

Trailer - Storage Boxes

Trailer boxes have cam-lock latches, strap hinges & feature drip-resistant jamb, huck-bolted doors, stitch-welded internal seams, auto-grade bulb seal and ACE Nameplate

Options include: Choice of smooth or checker plate finish, latch and door material upgrades. Custom sizes are available. Contact Factory for details.

Single Door Trailer Box
Part No. Description WxDxH (in) Wt. (lbs)
TB242424LH Box 24Wx24Dx24H, flush door box, aluminum cam lock - smooth 24 x 24 x 24 52
TB242424RH Box 24Wx24Dx24H, flush door box, aluminum cam lock - smooth 24 x 24 x 24 52
3' Trailer Boxes
Part No. Description WxDxH (in) Wt. (lbs)
TB362424 Box 36Wx24Dx24H, double flush door box, aluminum cam lock - smooth 36 x 24 x 24 71
4' Trailer Boxes
Part No. Description WxDxH (in) Wt. (lbs)
TB482424 Box 48Wx24Dx24H, double flush door box, aluminum cam lock - smooth 48 x 24 x 24 87
TB481818 Box 48Wx18Dx18H, double flush door box, aluminum cam lock - smooth 48 x 18 x 18 65
TB482424CP Box 48Wx24Dx24H, double flush door box, aluminum cam lock - checker 48 x 24 x 24 87
TB482430 Box 48Wx24Dx30H, double flush door box, aluminum cam lock - smooth 48 x 24 x 30 98
TB552420 Box 55Wx24Dx20H, double flush door box, aluminum cam lock - smooth 55 x 24 x 20 85
5' Trailer Boxes
Part No. Description WxDxH (in) Wt. (lbs)
TB602424 Box 60Wx24Dx24H, double flush door box, aluminum cam lock - smooth 60 x 24 x 24 103
TB601818 Box 60Wx18Dx18H, double flush door box, aluminum cam lock - smooth 60 x 18 x 18 80
TB602424CP Box 60Wx24Dx24H, double flush door box, aluminum cam lock - checker 60 x 24 x 24 103
